Zettler Magnetics ACST-261-1
- Part No.:
- ACST-261-1
- Manufacturer:
- Zettler Magnetics
- Category:
- Current Sense Transformers
- Package:
- Datasheet:
-
ACST-261-1.pdf
- Description:
- CURRENT SENSE TRANSFORMER
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
ACST-261-1 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Zettler Magnetics
- Series:
- ACST-200
- Packaging:
- Tray
- Product Status:
- Active
- Frequency Range:
- 50Hz ~ 200Hz
- Type:
- Invasive
- Current Rating (Amps):
- 30 A
- Inductance:
- 2.4 H
- ET (Volt-Time):
- -
- Turns Ratio - Primary:Secondary:
- 1:1000
- Current Ratio:
- 1000:1
- DC Resistance (DCR):
- 0.6mOhm
- Ratings:
- -
- Mounting Type:
- Through Hole
- Size / Dimension:
- 0.807" L x 0.690" W (20.50mm x 17.53mm)
- Height - Seated (Max):
- 0.650" (16.51mm)
- Termination Style:
- PC Pin
| Image |  |
 |
| Part Number | ACST-261-1 | ACST-260-1 |
| Manufacturer | Zettler Magnetics | Zettler Magnetics |
| Series | ACST-200 | ACST-200 |
| Packaging | Tray | Tray |
| Product Status | Active | Active |
| Frequency Range | 50Hz ~ 200Hz | 50Hz ~ 200Hz |
| Type | Invasive | Invasive |
| Current Rating (Amps) | 30 A | 30 A |
| Inductance | 2.4 H | 730 mH |
| ET (Volt-Time) | - | - |
| Turns Ratio - Primary:Secondary | 1:1000 | 1:500 |
| Current Ratio | 1000:1 | 500:1 |
| DC Resistance (DCR) | 0.6mOhm | 0.6mOhm |
| Ratings | - | - |
| Mounting Type | Through Hole | Through Hole |
| Size / Dimension | 0.807" L x 0.690" W (20.50mm x 17.53mm) | 0.807" L x 0.690" W (20.50mm x 17.53mm) |
| Height - Seated (Max) | 0.650" (16.51mm) | 0.650" (16.51mm) |
| Termination Style | PC Pin | PC Pin |
