Innolux S370AJ1-LE1 Rev.C1

Name: S370AJ1-LE1 Rev.C1
Brand: Innolux
SKU: S370AJ1-LE1 Rev.C1
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: S370AJ1-LE1 Rev.C1

Manufacturer:: Innolux

Category:: TFT-LCD Panel

Package:

Description:: Innolux 37" Stretched VA LCM 1920×540 1000nits WLED LVDS 51pins

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

S370AJ1-LE1 Rev.C1 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Innolux

Panel Size:: 37"

TNVAIPS:: VA

Resolution:: 1920×540

CR:: 1900/7/26 8:01:00

Viewing Angle:: 89/89/89/89

Colors:: 16.7M

Outline Size:: 923.3(H)×277.1(V)×28.4(D) mm

Treatment:: Antiglare (Haze 1%), Hard coating (3H)

Brightness:: 1000 cd/m² (Typ.)

Contrast Ratio:: 5000:1 (Typ.) (TM)

View Direction:: Symmetry

Viewing Angle:: 89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)

Response Time:: 11 (Typ.)(G to G)

Best View on:

Work Mode:: Super MVA, Normally Black, Transmissive

Glass Thickness:

Transmissivity:

Color Depth:: 16.7M 72% NTSC

Mass:: 4.67±0.23Kgs

Used for:: Digital Signage; Outdoor High Brightness; Stretched Bar LCD

Touch Screen:: Without

Refresh Rate:: 60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)

Part Number	S370AJ1-LE1	S370AJ1-LE1 Rev.B5	S370AJ1-LE1 Rev.C1	S370AJ1-LE1 Rev.C2
Manufacturer	Innolux	Innolux	Innolux	Innolux
Panel Size	37"	37"	37"	37"
TNVAIPS	VA	VA	VA	VA
Resolution	1920×540	1920×540	1920×540	1920×540
CR	1900/7/26 8:01:00	1900/7/26 8:01:00	1900/7/26 8:01:00	1900/7/26 8:01:00
Viewing Angle	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89
Colors	16.7M	16.7M	16.7M	16.7M
Outline Size	923.3(W)×277.1(H) ×28.4(D) mm	923.3(W)×277.1(H) ×24.3(D) mm	923.3(H)×277.1(V)×28.4(D) mm	923.3 × 277.1 × 28.4 (H×V×D)
Treatment	Antiglare (Haze 1%), Hard coating (3H)	Antiglare (Haze 1%), Hard coating (3H)	Antiglare (Haze 1%), Hard coating (3H)	Antiglare (Haze 28%), Hard coating (3H)
Brightness	1000 cd/m² (Typ.)	1000 cd/m² (Typ.)	1000 cd/m² (Typ.)	2500 cd/m² (Typ.)
Contrast Ratio	5000:1 (Typ.) (TM)	5000:1 (Typ.) (TM)	5000:1 (Typ.) (TM)	5000 : 1 (Typ.) (TM)
View Direction			Symmetry
Viewing Angle	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)
Response Time	11 (Typ.)(G to G)	11 (Typ.)(G to G)	11 (Typ.)(G to G)	11 (Typ.)(G to G) ms
Best View on	Symmetry	Symmetry		Symmetry
Work Mode	Super MVA, Normally Black, Transmissive	Super MVA, Normally Black, Transmissive	Super MVA, Normally Black, Transmissive	Super MVA, Normally Black, Transmissive
Glass Thickness
Transmissivity
Color Depth	16.7M 72% NTSC	16.7M 72% NTSC	16.7M 72% NTSC	16.7M 72% NTSC
Mass	4.67±0.23Kgs	4.31±0.22Kgs	4.67±0.23Kgs	4.67±0.23Kgs
Used for	Digital Signage; Outdoor High Brightness; Stretched Bar LCD	Digital Signage; Outdoor High Brightness; Stretched Bar LCD	Digital Signage; Outdoor High Brightness; Stretched Bar LCD	Digital Signage; Outdoor High Brightness; Stretched Bar LCD
Touch Screen	Without	Without	Without	Without
Refresh Rate	60Hz	60Hz	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz
