Nexperia USA Inc. PSMN9R5-30YLC,115

Product attributes

Attribute value

Manufacturer:

Nexperia USA Inc.

Series:

-

Package/Case:

SC-100, SOT-669

Packaging:

Tape & Reel (TR)

Product Status:

Active

FET Type:

N-Channel

Technology:

MOSFET (Metal Oxide)

Drain to Source Voltage (Vdss):

30 V

Current - Continuous Drain (Id) @ 25°C:

44A (Tc)

Drive Voltage (Max Rds On, Min Rds On):

4.5V, 10V

Rds On (Max) @ Id, Vgs:

9.8mOhm @ 15A, 10V

Vgs(th) (Max) @ Id:

1.95V @ 1mA

Gate Charge (Qg) (Max) @ Vgs:

10.4 nC @ 10 V

Vgs (Max):

±20V

Input Capacitance (Ciss) (Max) @ Vds:

681 pF @ 15 V

FET Feature:

-

Power Dissipation (Max):

34W (Tc)

Operating Temperature:

-55°C ~ 175°C (TJ)

Grade:

-

Qualification:

-

Mounting Type:

Surface Mount

Supplier Device Package:

LFPAK56, Power-SO8
