AUO P215HAN02.0
- Part No.:
- P215HAN02.0
- Manufacturer:
- AUO
- Category:
- TFT-LCD Panel
- Package:
- Description:
- AUO 21.5" IPS LCM 1920×1080 1500nits WLED LVDS 30pins
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Product Details
P215HAN02.0 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- AUO
- Panel Size:
- 21.5"
- TNVAIPS:
- IPS
- Resolution:
- 1920×1080
- CR:
- 1900/2/10 16:01:00
- Viewing Angle:
- 89/89/89/89
- Colors:
- 16.7M
- Outline Size:
- 501.1(H)×292.2(V) ×16.12(D) mm
- Treatment:
- Antiglare, Hard coating (3H)
- Brightness:
- 1500 cd/m² (Typ.)
- Contrast Ratio:
- 1000:1 (Typ.) (TM)
- View Direction:
- Symmetry
- Viewing Angle:
- 89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)
- Response Time:
- 25 (Typ.)(Tr+Td)
- Best View on:
- Work Mode:
- AHVA, Normally Black, Transmissive
- Glass Thickness:
- Transmissivity:
- Color Depth:
- 16.7M 72% NTSC
- Mass:
- 2.10Kgs (Typ.)
- Used for:
- Digital Signage; Outdoor High Brightness
- Touch Screen:
- Without
- Refresh Rate:
- 60Hz
| Image |  |
 |
| Part Number | P215HAN02.0 | P215HAN02.1 |
| Manufacturer | AUO | AUO |
| Panel Size | 21.5" | 21.5" |
| TNVAIPS | IPS | IPS |
| Resolution | 1920×1080 | 1920×1080 |
| CR | 1900/2/10 16:01:00 | 1900/2/10 16:01:00 |
| Viewing Angle | 89/89/89/89 | 89/89/89/89 |
| Colors | 16.7M | 16.7M |
| Outline Size | 501.1(H)×292.2(V) ×16.12(D) mm | |
| Treatment | Antiglare, Hard coating (3H) | |
| Brightness | 1500 cd/m² (Typ.) | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) | |
| View Direction | Symmetry | |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down) | 89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down) |
| Response Time | 25 (Typ.)(Tr+Td) | |
| Best View on | Symmetry | |
| Work Mode | AHVA, Normally Black, Transmissive | |
| Glass Thickness | ||
| Transmissivity | ||
| Color Depth | 16.7M 72% NTSC | 16.7M |
| Mass | 2.10Kgs (Typ.) | - |
| Used for | Digital Signage; Outdoor High Brightness | |
| Touch Screen | Without | |
| Refresh Rate | 60Hz | 60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit) |
