BOE NT140FHM-N41
- Part No.:
- NT140FHM-N41
- Manufacturer:
- BOE
- Category:
- TFT-LCD Panel
- Package:
- Description:
- BOE 14" TN LCM 1920×1080 200nits WLED eDP 30pins BOE06B2
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Product Details
NT140FHM-N41 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- BOE
- Panel Size:
- 14"
- TNVAIPS:
- TN
- Resolution:
- 1920×1080
- CR:
- 1900/1/20 20:01:00
- Viewing Angle:
- 45/45/20/40
- Colors:
- 262K
- Outline Size:
- 320.4(W)×205.1(H) ×3(D) mm
- Treatment:
- Antiglare
- Brightness:
- 200 cd/m² (Typ.)
- Contrast Ratio:
- 500:1 (Typ.) (TM)
- View Direction:
- Viewing Angle:
- 45/45/20/40 (Typ.)(CR≥10)
- Response Time:
- 16 (Typ.)(Tr+Td)
- Best View on:
- 6 o'clock
- Work Mode:
- TN, Normally White, Transmissive
- Glass Thickness:
- Transmissivity:
- Color Depth:
- 262K 47% NTSC
- Mass:
- Used for:
- Touch Screen:
- Without
- Refresh Rate:
- 60Hz
| Image |  |
 |
 |
 |
 |
| Part Number | NT140FHM-N41 | NT140FHM-N44 | NT140FHM-N43 | NT140FHM-N42 | NT140FHM-N45 |
| Manufacturer | BOE | BOE | BOE | BOE | BOE |
| Panel Size | 14" | 14" | 14" | 14" | 14" |
| TNVAIPS | TN | TN | TN | TN | TN |
| Resolution | 1920×1080 | 1920×1080 | 1920×1080 | 1920×1080 | 1920×1080 |
| CR | 1900/1/20 20:01:00 | 1900/1/20 20:01:00 | 1900/1/20 20:01:00 | 1900/1/16 16:01:00 | 1900/1/20 20:01:00 |
| Viewing Angle | 45/45/20/40 | 45/45/20/40 | 45/45/20/40 | 45/45/20/40 | 45/45/20/40 |
| Colors | 262K | 16.2M | 16.2M | 262K | 16.2M |
| Outline Size | 320.4(W)×205.1(H) ×3(D) mm | 315.8(W)×197.45(H)×3(D) | 315.8(W)×197.45(H)×3(D) mm | 320.4(W)×205.1(H) ×3(D) mm | 315.81(H)×195.55(V) ×3(D) mm |
| Treatment | Antiglare | Antiglare, Hard coating (3H) | Antiglare | Antiglare, Hard coating (3H) | |
| Brightness | 200 cd/m² (Typ.) | 220 (Typ.)(cd/m²) | 220 cd/m² (Typ.) | 300 cd/m² (Typ.) | 250 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) | 500 : 1 (Typ.) (TM) | 400:1 (Typ.) (TM) | 500:1 (Typ.) (TM) | |
| View Direction | 6 o'clock | ||||
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥10) | 45/45/20/40 (Typ.)(CR≥10) | 45/45/20/40 (Typ.)(CR≥10) (Left / Right / Up / Down) | 45/45/20/40 (Typ.)(CR≥10) (Left / Right / Up / Down) | 45/45/20/40 (Typ.)(CR≥10) (Left / Right / Up / Down) |
| Response Time | 16 (Typ.)(Tr+Td) | 12 (Typ.)(Tr+Td) ms | 16 (Typ.)(Tr+Td) | 12 (Typ.)(Tr+Td) | |
| Best View on | 6 o'clock | 6 o'clock | 6 o'clock | 6 o'clock | |
| Work Mode | TN, Normally White, Transmissive | TN, Normally White, Transmissive | TN, Normally White, Transmissive | TN, Normally White, Transmissive | |
| Glass Thickness | |||||
| Transmissivity | |||||
| Color Depth | 262K 47% NTSC | 16.2M 45% NTSC | 16.2M 45% NTSC | 262K 60% NTSC | 16.2M 45% NTSC |
| Mass | |||||
| Used for | Laptop | Laptop | |||
| Touch Screen | Without | Without | Without | Without | |
| Refresh Rate | 60Hz | 60Hz | 60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit) | 60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit) | 60Hz |
