Innolux M170EGE-L20

Name: M170EGE-L20
Brand: Innolux
SKU: M170EGE-L20
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: M170EGE-L20

Manufacturer:: Innolux

Category:: TFT-LCD Panel

Package:

Description:: Innolux 17" TN LCM 1280×1024 250nits WLED LVDS 30pins

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

M170EGE-L20 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Innolux

Panel Size:: 17"

TNVAIPS:: TN

Resolution:: 1280×1024

CR:: 1900/2/10 16:01:00

Viewing Angle:: 85/85/80/80

Colors:: 16.7M

Outline Size:: 358.5(W)×296.5(H) ×11(D) mm

Treatment:: Antiglare (Haze 25%), Hard coating (3H)

Brightness:: 250 cd/m² (Typ.)

Contrast Ratio:: 1000:1 (Typ.) (TM)

View Direction:

Viewing Angle:: 85/85/80/80 (Typ.)(CR≥10) (Left / Right / Up / Down)

Response Time:: 1/4 (Typ.)(Tr/Td)

Best View on:: 6 o'clock

Work Mode:: TN, Normally White, Transmissive

Glass Thickness:

Transmissivity:

Color Depth:: 16.7M 72% NTSC

Mass:: 1.40/1.50Kgs (Typ./Max.)

Used for:: Industrial

Touch Screen:: Without

Refresh Rate:: 60Hz

Part Number	M170EGE-L20	M170EGE-L20 Rev.C2	M170EGE-L20 Rev.C3	M170EGE-L20 Rev.C4
Manufacturer	Innolux	Innolux	Innolux	Innolux
Panel Size	17"	17"	17"	17"
TNVAIPS	TN	TN	TN	TN
Resolution	1280×1024	1280×1024	1280×1024	1280×1024
CR	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/10 16:01:00
Viewing Angle	85/85/80/80	85/85/80/80	85/85/80/80	85/85/80/80
Colors	16.7M	16.7M	16.7M	16.7M
Outline Size	358.5(W)×296.5(H) ×11(D) mm	358.5 × 296.5 × 11 (H×V×D)	358.5(W)×296.5(H) ×11(D) mm	358.5(H)×296.5(V) ×11(D) mm
Treatment	Antiglare (Haze 25%), Hard coating (3H)	Antiglare (Haze 25%), Hard coating (3H)	Antiglare (Haze 25%), Hard coating (3H)
Brightness	250 cd/m² (Typ.)	250 cd/m² (Typ.)	250 cd/m² (Typ.)	250 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)	1000 : 1 (Typ.) (TM)	1000:1 (Typ.) (TM)
View Direction				6 o'clock
Viewing Angle	85/85/80/80 (Typ.)(CR≥10) (Left / Right / Up / Down)	85/85/80/80 (Typ.)(CR≥10) (Left / Right / Up / Down)	85/85/80/80 (Typ.)(CR≥10)	85/85/80/80 (Typ.)(CR≥10) (Left / Right / Up / Down)
Response Time	1/4 (Typ.)(Tr/Td)	1/4 (Typ.)(Tr/Td) ms	1/4 (Typ.)(Tr/Td)
Best View on	6 o'clock	6 o'clock	6 o'clock
Work Mode	TN, Normally White, Transmissive	TN, Normally White, Transmissive	TN, Normally White, Transmissive
Glass Thickness
Transmissivity
Color Depth	16.7M 72% NTSC	16.7M 72% NTSC	16.7M 72% NTSC	16.7M 72% NTSC
Mass	1.40/1.50Kgs (Typ./Max.)	1.40/1.50Kgs (Typ./Max.)	1.40/1.50Kgs (Typ./Max.)	1.40/1.50Kgs (Typ./Max.)
Used for	Industrial	Desktop Monitor; Industrial
Touch Screen	Without	Without	Without
Refresh Rate	60Hz	75Hz	75Hz	75Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)
