KOE LMG7420PLFC-X
- Part No.:
- LMG7420PLFC-X
- Manufacturer:
- KOE
- Category:
- STN Graphic Display
- Package:
- Description:
- KOE 5.1" 240×128 FSTN-LCD Black/White (Negative) Transmissive CCFL T6963C CPU 20pins
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Product Details
LMG7420PLFC-X Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- KOE
- Panel Size:
- 5.1"
- Panel Type:
- FSTN-LCD
- Resolution:
- 240×128
- Viewing Area:
- 124.0×70.0
- Outline Size:
- 159.4(H)×101(V) ×12(D) mm
- Treatment:
- Antiglare, Hard coating (3H)
- Brightness:
- 150 cd/m² (Typ.)
- Contrast Ratio:
- 20:1 (Typ.) (TM)
- View Direction:
- 6 o'clock
- Viewing Angle:
- 40/40/40/40 (Typ.)(CR≥2) (Left / Right / Up / Down)
- Response Time:
- 160/110 (Typ.)(Tr/Td)
- Best View on:
- Work Mode:
- STN, Black/White (Negative), Transmissive
- Glass Thickness:
- Transmissivity:
- Color Depth:
- Monochrome
- Backlight:
- CCFL [1 pcs] , 50K hours , W/O Driver
- Mass:
- 180g (Typ.)
- Touch Screen:
- Without
- Refresh Rate:
- 75Hz
- Driver IC list:
- Signal Type:
- 8-bit parallel , 20 pins Connector
| Image |  |
 |
| Part Number | LMG7420PLFC-X | LMG7420PLFC |
| Manufacturer | KOE | KOE |
| Panel Size | 5.1" | 5.1" |
| Panel Type | FSTN-LCD | FSTN-LCD |
| Resolution | 240×128 | 240×128 |
| Viewing Area | 124.0×70.0 | |
| Outline Size | 159.4(H)×101(V) ×12(D) mm | |
| Treatment | Antiglare, Hard coating (3H) | |
| Brightness | 150 cd/m² (Typ.) | |
| Contrast Ratio | 20:1 (Typ.) (TM) | |
| View Direction | 6 o'clock | |
| Viewing Angle | 40/40/40/40 (Typ.)(CR≥2) (Left / Right / Up / Down) | - |
| Response Time | 160/110 (Typ.)(Tr/Td) | |
| Best View on | - | |
| Work Mode | STN, Black/White (Negative), Transmissive | |
| Glass Thickness | ||
| Transmissivity | ||
| Color Depth | Monochrome | Monochrome |
| Backlight | CCFL [1 pcs] , 50K hours , W/O Driver | |
| Mass | 180g (Typ.) | - |
| Touch Screen | Without | |
| Refresh Rate | 75Hz | |
| Driver IC list | ||
| Signal Type | 8-bit parallel , 20 pins Connector | 8-bit parallel |
