LG Display LC600EQF-DJF1

Name: LC600EQF-DJF1
Brand: LG Display
SKU: LC600EQF-DJF1
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: LC600EQF-DJF1

Manufacturer:: LG Display

Category:: TFT-LCD Panel

Package:

Description:: LG Display 60" IPS LCM 3840×2160 400nits WLED V-by-One 92pins 120Hz

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

LC600EQF-DJF1 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: LG Display

Panel Size:: 60"

TNVAIPS:: IPS

Resolution:: 3840×2160

CR:: 1900/2/27 8:01:00

Viewing Angle:: 89/89/89/89

Colors:: 16.7M/1.07B

Outline Size:: 1348(H)×777.1(V) ×28.8(D) mm

Treatment:: Antiglare (Haze 3%), Hard coating (2H)

Brightness:: 400 cd/m² (Typ.)

Contrast Ratio:: 1400:1 (Typ.) (TM)

View Direction:: Symmetry

Viewing Angle:: 89/89/89/89 (Min.)(CR≥10) (Left / Right / Up / Down)

Response Time:: 5 (Typ.)(G to G), 8 (Typ.)(MPRT)

Best View on:

Work Mode:: IPS, Normally Black, Transmissive

Glass Thickness:

Transmissivity:

Color Depth:: 16.7M/1.07B 70% NTSC

Mass:: 17.2/17.8Kgs (Typ./Max.)

Used for:: TV Sets

Touch Screen:: Without

Refresh Rate:: 120Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)

Part Number	LC600EQF-PHF1	LC600EQF-FHM1	LC600EQF-FHM2	LC600EQF-DJF1
Manufacturer	LG Display	LG Display	LG Display	LG Display
Panel Size	60"	60"	60"	60"
TNVAIPS	IPS	IPS	IPS	IPS
Resolution	3840×2160	3840×2160	3840×2160	3840×2160
CR	1900/2/19 0:01:00	1900/2/27 8:01:00	1900/2/27 8:01:00	1900/2/27 8:01:00
Viewing Angle	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89
Colors	16.7M/1.07B	1.07B	1.07B	16.7M/1.07B
Outline Size	1333.8(W)×764.7(H) ×28.3(D) mm	1341.1(W)×767.4(H)×30.4(D) mm	1341.1 × 767.4 × 31.4 (H×V×D)	1348(H)×777.1(V) ×28.8(D) mm
Treatment	Antiglare (Haze 1%), Hard coating (2H)	Antiglare (Haze 1%), Hard coating (3H)	Antiglare (Haze 1%), Hard coating (3H)	Antiglare (Haze 3%), Hard coating (2H)
Brightness	450 cd/m² (Typ.)	400 cd/m² (Typ.)	400 cd/m² (Typ.)	400 cd/m² (Typ.)
Contrast Ratio	1200:1 (Typ.) (TM)	1400:1 (Typ.) (TM)	1400 : 1 (Typ.) (TM)	1400:1 (Typ.) (TM)
View Direction		Symmetry		Symmetry
Viewing Angle	89/89/89/89 (Min.)(CR≥10)	89/89/89/89 (Min.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Min.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Min.)(CR≥10) (Left / Right / Up / Down)
Response Time	5 (Typ.)(G to G), 8 (Typ.)(MPRT)	5 (Typ.)(G to G), 8 (Typ.)(MPRT)	5 (Typ.)(G to G), 8 (Typ.)(MPRT) ms	5 (Typ.)(G to G), 8 (Typ.)(MPRT)
Best View on	Symmetry		Symmetry
Work Mode	IPS, Normally Black, Transmissive	IPS, Normally Black, Transmissive	IPS, Normally Black, Transmissive	IPS, Normally Black, Transmissive
Glass Thickness
Transmissivity
Color Depth	16.7M/1.07B 70% NTSC	1.07B 72% NTSC	1.07B 72% NTSC	16.7M/1.07B 70% NTSC
Mass	17.1/17.9Kgs (Typ./Max.)	18.0/18.9Kgs (Typ./Max.)	18.0/18.9Kgs (Typ./Max.)	17.2/17.8Kgs (Typ./Max.)
Used for		TV Sets	TV Sets	TV Sets
Touch Screen	Without	Without	Without	Without
Refresh Rate	120Hz	120Hz	120Hz	120Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)
