AUO G190EAN01.3

Name: G190EAN01.3
Brand: AUO
SKU: G190EAN01.3
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: G190EAN01.3

Manufacturer:: AUO

Category:: TFT-LCD Panel

Package:

Description:: AUO 19" IPS LCM 1280×1024 330nits WLED LVDS 30pins

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

G190EAN01.3 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: AUO

Panel Size:: 19"

TNVAIPS:: IPS

Resolution:: 1280×1024

CR:: 1900/2/10 16:01:00

Viewing Angle:: 89/89/89/89

Colors:: 16.7M

Outline Size:: 396(W)×324(H) ×15.8(D) mm

Treatment:: Antiglare

Brightness:: 330 cd/m² (Typ.)

Contrast Ratio:: 1000:1 (Typ.) (TM)

View Direction:

Viewing Angle:: 89/89/89/89 (Typ.)(CR≥10)

Response Time:: 13/12 (Typ.)(Tr/Td)

Best View on:: Symmetry

Work Mode:: AHVA, Normally Black, Transmissive

Glass Thickness:

Transmissivity:

Color Depth:: 16.7M 72% NTSC

Mass:: 1.70±0.15Kgs

Used for:

Touch Screen:: Without

Refresh Rate:: 60Hz

Part Number	G190EAN01.0	G190EAN01.3	G190EAN01.5	G190EAN01.6	G190EAN01.1
Manufacturer	AUO	AUO	AUO	AUO	AUO
Panel Size	19"	19"	19"	19"	19"
TNVAIPS	IPS	IPS	IPS	IPS	IPS
Resolution	1280×1024	1280×1024	1280×1024	1280×1024	1280×1024
CR	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/10 16:01:00
Viewing Angle	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89
Colors	16.7M	16.7M	16.7M	16.7M	Grayscale
Outline Size	396(W)×324(H) ×17.5(D) mm	396(W)×324(H) ×15.8(D) mm	396×324×15.8 (H×V×D)	396(H)×324(V) ×15.8(D) mm	396 × 324 × 17.5 (H×V×D)
Treatment		Antiglare	Antiglare	Antiglare	Antiglare
Brightness	300 cd/m² (Typ.)	330 cd/m² (Typ.)	700 cd/m² (Typ.)	1000 cd/m² (Typ.)	1300 cd/m² (Typ.)
Contrast Ratio		1000:1 (Typ.) (TM)	1000 : 1 (Typ.) (TM)	1000:1 (Typ.) (TM)	1000 : 1 (Typ.) (TM)
View Direction				Symmetry
Viewing Angle	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)
Response Time		13/12 (Typ.)(Tr/Td)	13/12 (Typ.)(Tr/Td) ms	13/12 (Typ.)(Tr/Td)	13/12 (Typ.)(Tr/Td) ms
Best View on	Symmetry	Symmetry	Symmetry		Symmetry
Work Mode		AHVA, Normally Black, Transmissive	AHVA, Normally Black, Transmissive	AHVA, Normally Black, Transmissive	AHVA, Normally Black, Transmissive
Glass Thickness
Transmissivity
Color Depth	16.7M 72% NTSC	16.7M 72% NTSC	16.7M 72% NTSC	16.7M 72% NTSC	Grayscale
Mass	1.55Kgs (Typ.)	1.70±0.15Kgs	1.70±0.15Kgs	1.70±0.15Kgs	1.55Kgs (Typ.)
Used for			Industrial; Medical Imaging; Outdoor High Brightness	Industrial; Medical Imaging; Outdoor High Brightness	Industrial; Medical Imaging; Outdoor High Brightness
Touch Screen		Without	Without	Without	Without
Refresh Rate	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)
