Innolux G156HCE-E01

Name: G156HCE-E01
Brand: Innolux
SKU: G156HCE-E01
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: G156HCE-E01

Manufacturer:: Innolux

Category:: TFT-LCD Panel

Package:

Description:: Innolux 15.6" IPS LCM 1920×1080 450nits WLED eDP 40pins

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

G156HCE-E01 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Innolux

Panel Size:: 15.6"

TNVAIPS:: IPS

Resolution:: 1920×1080

CR:: 1900/2/10 16:01:00

Viewing Angle:: 89/89/89/89

Colors:: 16.7M

Outline Size:: 351.84(W)×208.88(H)×6.5(D) mm

Treatment:: Antiglare, Hard coating (3H)

Brightness:: 450 cd/m² (Typ.)

Contrast Ratio:: 1000:1 (Typ.) (TM)

View Direction:: Symmetry

Viewing Angle:: 89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)

Response Time:: 14/11 (Typ.)(Tr/Td)

Best View on:

Work Mode:: AAS, Normally Black, Transmissive

Glass Thickness:

Transmissivity:

Color Depth:: 16.7M 72% NTSC

Mass:: 550g (Typ.)

Used for:: Industrial; Gaming

Touch Screen:: Without

Refresh Rate:: 60Hz

Part Number	G156HCE-L01	G156HCE-E01	G156HCE-LN1	G156HCE-LH1	G156HCE-LN2
Manufacturer	Innolux	Innolux	Innolux	Innolux	Innolux
Panel Size	15.6"	15.6"	15.6"	15.6"	15.6"
TNVAIPS	IPS	IPS	IPS	IPS	IPS
Resolution	1920×1080	1920×1080	1920×1080	1920×1080	1920×1080
CR	1900/2/2 8:01:00	1900/2/10 16:01:00	1900/2/2 8:01:00	1900/2/2 8:01:00	1900/2/2 8:01:00
Viewing Angle	85/85/85/85	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89
Colors	16.2M	16.7M	16.7M	16.7M	16.7M
Outline Size	363.8(H)×215.98(V) ×9.6(D) mm	351.84(W)×208.88(H)×6.5(D) mm	363.8(W)×215.9(H) ×9.8(D) mm	363.8(W)×215.9(H) ×12.5(D) mm	363.8(W)×215.9(H)×9.8(D) mm
Treatment		Antiglare, Hard coating (3H)	Antiglare, Hard coating (3H)	Antiglare, Hard coating (3H)	Antiglare, Hard coating (3H)
Brightness	450 cd/m² (Typ.)	450 cd/m² (Typ.)	350 cd/m² (Typ.)	1200 cd/m² (Typ.)	500 cd/m² (Typ.)
Contrast Ratio		1000:1 (Typ.) (TM)	800:1 (Typ.) (TM)	800:1 (Typ.) (TM)	800:1 (Typ.) (TM)
View Direction	Symmetry	Symmetry			Symmetry
Viewing Angle	85/85/85/85 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10)	89/89/89/89 (Typ.)(CR≥10)	89/89/89/89 (Typ.)(CR≥10)
Response Time		14/11 (Typ.)(Tr/Td)	14/11 (Typ.)(Tr/Td)	14/11 (Typ.)(Tr/Td)	14/11 (Typ.)(Tr/Td)
Best View on			Symmetry	Symmetry
Work Mode		AAS, Normally Black, Transmissive	AAS, Normally Black, Transmissive	AAS, Normally Black, Transmissive	AAS, Normally Black, Transmissive
Glass Thickness
Transmissivity
Color Depth	16.2M 73% NTSC	16.7M 72% NTSC	16.7M 73% NTSC	16.7M 73% NTSC	16.7M 73% NTSC
Mass	1.06/1.10Kgs (Typ./Max.)	550g (Typ.)	1.06/1.10Kgs (Typ./Max.)	815±41g	1.06/1.10Kgs (Typ./Max.)
Used for		Industrial; Gaming
Touch Screen		Without	Without	Without	Without
Refresh Rate	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz	60Hz	60Hz	60Hz
