Innolux G121ICE-L02

Name: G121ICE-L02
Brand: Innolux
SKU: G121ICE-L02
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: G121ICE-L02

Manufacturer:: Innolux

Category:: TFT-LCD Panel

Package:

Description:: Innolux 12.1" IPS LCM 1280×800 400nits WLED LVDS 30pins

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

G121ICE-L02 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Innolux

Panel Size:: 12.1"

TNVAIPS:: IPS

Resolution:: 1280×800

CR:: 1900/2/10 16:01:00

Viewing Angle:: 89/89/89/89

Colors:: 262K/16.7M

Outline Size:: 278(W)×184(H) ×10.5(D) mm

Treatment:

Brightness:: 400 cd/m² (Typ.)

Contrast Ratio:

View Direction:

Viewing Angle:: 89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)

Response Time:

Best View on:: Symmetry

Work Mode:

Glass Thickness:

Transmissivity:

Color Depth:: 262K/16.7M 72% NTSC

Mass:: 470/490g (Typ./Max.)

Used for:

Touch Screen:

Refresh Rate:: 60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)

Part Number	G121ICE-L01	G121ICE-L02	G121ICE-LH1	G121ICE-LH2	G121ICE-LM2
Manufacturer	Innolux	Innolux	Innolux	Innolux	Innolux
Panel Size	12.1"	12.1"	12.1"	12.1"	12.1"
TNVAIPS	IPS	IPS	IPS	IPS	IPS
Resolution	1280×800	1280×800	1280×800	1280×800	1280×800
CR	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/10 16:01:00	1900/2/10 16:01:00
Viewing Angle	89/89/89/89	89/89/89/89	89/89/89/89	88/88/88/88	88/88/88/88
Colors	262K/16.7M	262K/16.7M	262K/16.7M	262K/16.7M	262K/16.7M
Outline Size	278(H)×184(V) ×10.5(D) mm	278(W)×184(H) ×10.5(D) mm	278(W)×184(H)×10.5(D) mm	278(W)×184(H)×9.61(D) mm	278(W)×184(H) ×9.61(D) mm
Treatment	Antiglare, Hard coating (3H)		Antiglare, Hard coating (3H)		Antiglare, Hard coating (3H)
Brightness	600 cd/m² (Typ.)	400 cd/m² (Typ.)	1000 cd/m² (Typ.)	600 cd/m² (Typ.)	400 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.) (TM)		1000:1 (Typ.) (TM)		1000:1 (Typ.) (TM)
View Direction	Symmetry		Symmetry
Viewing Angle	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	88/88/88/88 (Typ.)(CR≥10) (Left / Right / Up / Down)	88/88/88/88 (Typ.)(CR≥10) (Left / Right / Up / Down)
Response Time	12/8 (Typ.)(Tr/Td)		13/12 (Typ.)(Tr/Td)		12/8 (Typ.)(Tr/Td)
Best View on		Symmetry		Symmetry	Symmetry
Work Mode	AAS, Normally Black, Transmissive		AAS, Normally Black, Transmissive		AAS, Normally Black, Transmissive
Glass Thickness
Transmissivity
Color Depth	262K/16.7M 72% NTSC	262K/16.7M 72% NTSC	262K/16.7M 72% NTSC	262K/16.7M	262K/16.7M
Mass	455/490g (Typ./Max.)	470/490g (Typ./Max.)	470/490g (Typ./Max.)	470/490g (Typ./Max.)	-
Used for	Industrial		Industrial; Outdoor High Brightness		Industrial
Touch Screen	Without		Without		Without
Refresh Rate	60Hz	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)
