Triad Magnetics F8-24
- Part No.:
- F8-24
- Manufacturer:
- Triad Magnetics
- Category:
- Power Transformers
- Package:
- Datasheet:
-
F8-24.pdf
- Description:
- PWR XFMR LAMINATED 100VA CHAS MT
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
F8-24 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Triad Magnetics
- Series:
- Quick Pack
- Packaging:
- Box
- Product Status:
- Active
- Type:
- Laminated Core
- Voltage - Primary:
- 115V
- Voltage - Secondary (Full Load):
- 24V
- Current - Output (Max):
- 4A
- Primary Winding(s):
- Single
- Secondary Winding(s):
- Single
- Center Tap:
- Yes
- Power - Max:
- 100VA
- Mounting Type:
- Chassis Mount
- Termination Style:
- Solder, Quick Connect - 0.187" (4.7mm)
- Size / Dimension:
- 102.39mm L x 57.15mm W
- Height - Seated (Max):
- 65.07mm
- Voltage - Isolation:
- 2500VAC
- Weight:
- 2.8 lbs (1.3 kg)
| Image |  |
 |
 |
 |
 |
| Part Number | F8-24 | F8-36 | F8-16 | F8-28 | F8-56 |
| Manufacturer | Triad Magnetics | Triad Magnetics | Triad Magnetics | Triad Magnetics | Triad Magnetics |
| Series | Quick Pack | Quick Pack | Quick Pack | Quick Pack | Quick Pack |
| Packaging | Box | Box | Box | Box | Box |
| Product Status | Active | Active | Active | Active | Active |
| Type | Laminated Core | Laminated Core | Laminated Core | Laminated Core | Laminated Core |
| Voltage - Primary | 115V | 115V | 115V | 115V | 115V |
| Voltage - Secondary (Full Load) | 24V | 36V | 16V | 28V | 56V |
| Current - Output (Max) | 4A | 2.8A | 6.25A | 3.6A | 1.8A |
| Primary Winding(s) | Single | Single | Single | Single | Single |
| Secondary Winding(s) | Single | Single | Single | Single | Single |
| Center Tap | Yes | Yes | Yes | Yes | Yes |
| Power - Max | 100VA | 100VA | 100VA | 100VA | 100VA |
| Mounting Type | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount |
| Termination Style | Solder, Quick Connect - 0.187" (4.7mm) | Solder, Quick Connect - 0.187" (4.7mm) | Solder, Quick Connect - 0.187" (4.7mm) | Solder, Quick Connect - 0.187" (4.7mm) | Solder, Quick Connect - 0.187" (4.7mm) |
| Size / Dimension | 102.39mm L x 57.15mm W | 102.39mm L x 57.15mm W | 102.39mm L x 57.15mm W | 102.39mm L x 57.15mm W | 102.39mm L x 57.15mm W |
| Height - Seated (Max) | 65.07mm | 65.07mm | 65.07mm | 65.07mm | 65.07mm |
| Voltage - Isolation | 2500VAC | 2500VAC | 2500VAC | 2500VAC | 2500VAC |
| Weight | 2.8 lbs (1.3 kg) | 2.8 lbs (1.3 kg) | 2.8 lbs (1.3 kg) | 2.8 lbs (1.3 kg) | 2.8 lbs (1.3 kg) |
