BOE EV156FHM-N10

Name: EV156FHM-N10
Brand: BOE
SKU: EV156FHM-N10
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: EV156FHM-N10

Manufacturer:: BOE

Category:: TFT-LCD Panel

Package:

Description:: BOE 15.6" IPS LCM 1920×1080 500nits WLED eDP 30pins

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

EV156FHM-N10 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: BOE

Panel Size:: 15.6"

TNVAIPS:: IPS

Resolution:: 1920×1080

CR:: 1900/2/19 0:01:00

Viewing Angle:: 89/89/89/89

Colors:: 16.7M

Outline Size:: 363.8(W)×216(H) ×9.9(D) mm

Treatment:

Brightness:: 500 cd/m² (Typ.)

Contrast Ratio:

View Direction:

Viewing Angle:: 89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)

Response Time:

Best View on:: Symmetry

Work Mode:

Glass Thickness:

Transmissivity:

Color Depth:: 16.7M 79% NTSC

Mass:: 850g (Max.)

Used for:

Touch Screen:

Refresh Rate:: 60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)

Part Number	EV156FHM-N10	EV156FHM-N11	EV156FHM-N80-3RA0	EV156FHM-N12	EV156FHM-N10-5850
Manufacturer	BOE	BOE	BOE	BOE	BOE
Panel Size	15.6"	15.6"	15.6"	15.6"	15.6"
TNVAIPS	IPS	IPS	IPS	IPS	IPS
Resolution	1920×1080	1920×1080	1920×1080	1920×1080	1920×1080
CR	1900/2/19 0:01:00	1900/2/19 0:01:00	1900/2/19 0:01:00	1900/2/19 0:01:00	1900/2/2 8:01:00
Viewing Angle	89/89/89/89	89/89/89/89	85/85/85/85	85/85/85/85	85/85/85/85
Colors	16.7M	16.7M	16.7M	16.7M	16.7M
Outline Size	363.8(W)×216(H) ×9.9(D) mm	363.8(H)×216(V) ×9.9(D) mm	350.66(H)×215.245(V)×2.9(D) mm	363.8(W)×215.9(H)×9.9(D) mm	363.8×215.9×9.9 (H×V×D)
Treatment		Antiglare (Haze 25%)	Antiglare (Haze 25%), Hard coating	Hard coating	Antiglare
Brightness	500 cd/m² (Typ.)	500 cd/m² (Typ.)	350 cd/m² (Typ.)	500 cd/m² (Typ.)	500 cd/m² (Typ.)
Contrast Ratio		1200:1 (Typ.) (TM)	1200:1 (Typ.) (TM)	1200:1 (Typ.) (TM)	800 : 1 (Typ.) (TM)
View Direction		Symmetry	Symmetry	Symmetry
Viewing Angle	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	89/89/89/89 (Typ.)(CR≥10) (Left / Right / Up / Down)	85/85/85/85 (Typ.)(CR≥10) (Left / Right / Up / Down)	85/85/85/85 (Typ.)(CR≥10)	85/85/85/85 (Typ.)(CR≥10) (Left / Right / Up / Down)
Response Time		25 (Typ.)(Tr+Td)	30 (Typ.)(Tr+Td)	25 (Typ.)(Tr+Td)	30 (Typ.)(Tr+Td) ms
Best View on	Symmetry				Symmetry
Work Mode		ADS, Normally Black, Transmissive	ADS, Normally Black, Transmissive	ADS, Normally Black, Transmissive	ADS, Normally Black, Transmissive
Glass Thickness
Transmissivity
Color Depth	16.7M 79% NTSC	16.7M 78% NTSC	16.7M 79% NTSC	16.7M 72% NTSC	16.7M 45% NTSC
Mass	850g (Max.)	850g (Max.)	320g (Max.)	850g (Max.)	850g (Max.)
Used for		Industrial; Healthcare	Industrial; Healthcare		Industrial
Touch Screen		Without	Without	Without	Without
Refresh Rate	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)
