Eaton - Electronics Division CTX5-4-R

Name: CTX5-4-R
Brand: Eaton - Electronics Division
SKU: CTX5-4-R
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: CTX5-4-R

Manufacturer:: Eaton - Electronics Division

Category:: Arrays, Signal Transformers

Package:: Nonstandard

Datasheet:: CTX5-4-R.pdf

Description:: INDUCT ARRAY 2 COIL 4.9UH SMD

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

CTX5-4-R Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Eaton - Electronics Division

Series:: OCTA-PAC®

Package/Case:: Nonstandard

Packaging:: Tape & Reel (TR)

Product Status:: Active

Number of Coils:: 2

Inductance - Connected In Parallel:: 4.9 µH

Inductance - Connected In Series:: 19.6 µH

Tolerance:: ±20%

Current Rating - Parallel:: 4.4 A

Current Rating - Series:: 2.2 A

Current Saturation - Parallel:: -

Current Saturation - Series:: -

DC Resistance (DCR) - Parallel:: 14mOhm Max

DC Resistance (DCR) - Series:: 56mOhm Max

Shielding:: Unshielded

Ratings:: -

Operating Temperature:: -40°C ~ 85°C

Mounting Type:: Surface Mount

Size / Dimension:: 0.550" L x 0.550" W (13.97mm x 13.97mm)

Height:: 0.250" (6.35mm)

Part Number	CTX5-4-R	CTX50-3P-R	CTX5-1-R	CTX50-4-R	CTX5-1P-R
Manufacturer	Eaton - Electronics Division	Eaton - Electronics Division	Eaton - Electronics Division	Eaton - Electronics Division	Eaton - Electronics Division
Series	OCTA-PAC®	Econo-Pac™	OCTA-PAC®	OCTA-PAC®	Econo-Pac™
Package/Case	Nonstandard	Nonstandard	Nonstandard	Nonstandard	Nonstandard
Packaging	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)
Product Status	Active	Active	Active	Active	Active
Number of Coils	2	2	2	2	2
Inductance - Connected In Parallel	4.9 µH	50.02 µH	4.9 µH	50.18 µH	4.83 µH
Inductance - Connected In Series	19.6 µH	200.1 µH	19.6 µH	200.7 µH	19.31 µH
Tolerance	±20%	±20%	±20%	±20%	±20%
Current Rating - Parallel	4.4 A	920 mA	2.3 A	1.5 A	2 A
Current Rating - Series	2.2 A	460 mA	1.15 A	750 mA	1 A
Current Saturation - Parallel	-	-	-	-	-
Current Saturation - Series	-	-	-	-	-
DC Resistance (DCR) - Parallel	14mOhm Max	277mOhm Max	30mOhm Max	111mOhm Max	40mOhm Max
DC Resistance (DCR) - Series	56mOhm Max	1.108Ohm Max	122mOhm Max	443mOhm Max	161mOhm Max
Shielding	Unshielded	Unshielded	Unshielded	Unshielded	Unshielded
Ratings	-	-	-	-	-
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C
Mounting Type	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount
Size / Dimension	0.550" L x 0.550" W (13.97mm x 13.97mm)	0.550" L x 0.550" W (13.97mm x 13.97mm)	0.450" L x 0.450" W (11.43mm x 11.43mm)	0.550" L x 0.550" W (13.97mm x 13.97mm)	0.450" L x 0.450" W (11.43mm x 11.43mm)
Height	0.250" (6.35mm)	0.190" (4.83mm)	0.165" (4.19mm)	0.250" (6.35mm)	0.165" (4.19mm)
