Soberton Inc. PT-1704
- Part No.:
- PT-1704
- Manufacturer:
- Soberton Inc.
- Category:
- Alarms, Buzzers, and Sirens
- Package:
- Datasheet:
-
PT-1704.pdf
- Description:
- BUZZER PIEZO 3V 17MM CUSTOM
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
PT-1704 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Soberton Inc.
- Series:
- PT
- Packaging:
- Tray
- Product Status:
- Active
- Driver Circuitry:
- Transducer, Externally Driven
- Input Type:
- Peak-Peak Signal
- Voltage - Rated:
- 3 V
- Voltage Range:
- 1 ~ 30V
- Frequency:
- 4kHz
- Technology:
- Piezo
- Operating Mode:
- Single Tone
- Duration:
- -
- Sound Pressure Level (SPL):
- 75dB @ 3V, 10cm
- Current - Supply:
- 3mA
- Port Location:
- Top
- Operating Temperature:
- -20°C ~ 70°C
- Approval Agency:
- -
- Ratings:
- -
- Ingress Protection:
- -
- Mounting Type:
- Custom
- Termination:
- Wire Leads
- Size / Dimension:
- 0.669" Dia (17.00mm)
| Image |  |
 |
 |
 |
|
| Part Number | PT-1704 | PT-2404 | PT-2207 | PT-1707 | PT-2309A |
| Manufacturer | Soberton Inc. | Soberton Inc. | Soberton Inc. | Soberton Inc. | Soberton Inc. |
| Series | PT | PT | PT | PT | - |
| Packaging | Tray | Tray | Tray | Tray | Tray |
| Product Status | Active | Active | Active | Active | Active |
| Driver Circuitry | Transducer, Externally Driven | Transducer, Externally Driven | Transducer, Externally Driven | Transducer, Externally Driven | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal | Peak-Peak Signal | Peak-Peak Signal | Peak-Peak Signal | Peak-Peak Signal |
| Voltage - Rated | 3 V | 15 V | 10 V | 5 V | 10 V |
| Voltage Range | 1 ~ 30V | 1 ~ 12V | 1 ~ 30V | 1 ~ 20V | 3 ~ 30V |
| Frequency | 4kHz | 4.8kHz | 4kHz | 4kHz | 2kHz |
| Technology | Piezo | Piezo | Piezo | Piezo | Piezo |
| Operating Mode | Single Tone | Single Tone | Single Tone | Single Tone | - |
| Duration | - | - | - | - | - |
| Sound Pressure Level (SPL) | 75dB @ 3V, 10cm | 85dB @ 4.8V, 10cm | 85dB @ 10V, 10cm | 78dB @ 5V, 10cm | 85dB @ 10V, 10cm |
| Current - Supply | 3mA | 8mA | 3mA | 1mA | 3.5mA |
| Port Location | Top | Top | Top | Top | Top |
| Operating Temperature | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 60°C | -20°C ~ 70°C |
| Approval Agency | - | - | - | - | - |
| Ratings | - | - | - | - | - |
| Ingress Protection | - | - | - | - | - |
| Mounting Type | Custom | Panel Mount, Flange | Through Hole | Through Hole | Through Hole |
| Termination | Wire Leads | Wire Leads | PC Pins | PC Pins | PC Pins |
| Size / Dimension | 0.669" Dia (17.00mm) | 0.945" Dia (24.00mm) | 0.866" Dia (22.00mm) | 0.669" Dia (17.00mm) | 0.858" Dia (21.80mm) |
