Diodes Incorporated DMC2038LVT-7
- Part No.:
- DMC2038LVT-7
- Manufacturer:
- Diodes Incorporated
- Category:
- FET, MOSFET Arrays
- Package:
- SOT-23-6 Thin, TSOT-23-6
- Description:
- MOSFET N/P-CH 20V 3.7A TSOT26
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
DMC2038LVT-7 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Diodes Incorporated
- Series:
- -
- Package/Case:
- SOT-23-6 Thin, TSOT-23-6
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Not For New Designs
- Technology:
- MOSFET (Metal Oxide)
- Configuration:
- N and P-Channel
- FET Feature:
- Logic Level Gate
- Drain to Source Voltage (Vdss):
- 20V
- Current - Continuous Drain (Id) @ 25°C:
- 3.7A, 2.6A
- Rds On (Max) @ Id, Vgs:
- 35mOhm @ 4A, 4.5V
- Vgs(th) (Max) @ Id:
- 1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:
- 17nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds:
- 530pF @ 10V
- Power - Max:
- 800mW
- Operating Temperature:
- -55°C ~ 150°C (TJ)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- TSOT-26
| Image |  |
 |
| Part Number | DMC2038LVT-7 | DMC2038LVTQ-7 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated |
| Series | - | - |
| Package/Case | SOT-23-6 Thin, TSOT-23-6 | SOT-23-6 Thin, TSOT-23-6 |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Not For New Designs | Not For New Designs |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Configuration | N and P-Channel | N and P-Channel Complementary |
| FET Feature | Logic Level Gate | Logic Level Gate, 1.8V Drive |
| Drain to Source Voltage (Vdss) | 20V | 20V |
| Current - Continuous Drain (Id) @ 25°C | 3.7A, 2.6A | 3.7A (Ta), 2.6A (Ta) |
| Rds On (Max) @ Id, Vgs | 35mOhm @ 4A, 4.5V | 35mOhm @ 4A, 4.5V, 74mOhm @ 3A, 4.5V |
| Vgs(th) (Max) @ Id | 1V @ 250µA | 1V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 17nC @ 10V | 5.7nC @ 4.5V, 10nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 530pF @ 10V | 530pF @ 10V, 705pF @ 10V |
| Power - Max | 800mW | 800mW (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Grade | - | Automotive |
| Qualification | - | AEC-Q101 |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | TSOT-26 | TSOT-23-6 |
