Eaton - Electronics Division CTX20-2P-R

Name: CTX20-2P-R
Brand: Eaton - Electronics Division
SKU: CTX20-2P-R
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: CTX20-2P-R

Manufacturer:: Eaton - Electronics Division

Category:: Arrays, Signal Transformers

Package:: Nonstandard

Datasheet:: CTX20-2P-R.pdf

Description:: INDUCT ARRAY 2 COIL 19.58UH SMD

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

CTX20-2P-R Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Eaton - Electronics Division

Series:: Econo-Pac™

Package/Case:: Nonstandard

Packaging:: Tape & Reel (TR)

Product Status:: Active

Number of Coils:: 2

Inductance - Connected In Parallel:: 19.58 µH

Inductance - Connected In Series:: 78.34 µH

Tolerance:: ±20%

Current Rating - Parallel:: 1.5 A

Current Rating - Series:: 750 mA

Current Saturation - Parallel:: -

Current Saturation - Series:: -

DC Resistance (DCR) - Parallel:: 97mOhm Max

DC Resistance (DCR) - Series:: 387mOhm Max

Shielding:: Unshielded

Ratings:: -

Operating Temperature:: -40°C ~ 85°C

Mounting Type:: Surface Mount

Size / Dimension:: 0.450" L x 0.450" W (11.43mm x 11.43mm)

Height:: 0.235" (5.97mm)

Part Number	CTX20-2P-R	CTX20-4P-R	CTX200-4-R	CTX200-2P-R	CTX20-4A-R
Manufacturer	Eaton - Electronics Division	Eaton - Electronics Division	Eaton - Electronics Division	Eaton - Electronics Division	Eaton - Electronics Division
Series	Econo-Pac™	Econo-Pac™	OCTA-PAC®	Econo-Pac™	OCTA-PAC® PLUS
Package/Case	Nonstandard	Nonstandard	Nonstandard	Nonstandard	Nonstandard
Packaging	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)
Product Status	Active	Active	Active	Active	Active
Number of Coils	2	2	2	2	2
Inductance - Connected In Parallel	19.58 µH	20.62 µH	200.7 µH	201.59 µH	19.58 µH
Inductance - Connected In Series	78.34 µH	82.47 µH	802.82 µH	806.34 µH	78.3 µH
Tolerance	±20%	±20%	±20%	±20%	±25%
Current Rating - Parallel	1.5 A	1.9 A	640 mA	460 mA	3.62 A
Current Rating - Series	750 mA	950 mA	320 mA	230 mA	1.81 A
Current Saturation - Parallel	-	-	-	-	3 A
Current Saturation - Series	-	-	-	-	1.5 A
DC Resistance (DCR) - Parallel	97mOhm Max	84mOhm Max	545mOhm Max	951mOhm Max	34mOhm Max
DC Resistance (DCR) - Series	387mOhm Max	337mOhm Max	2.18Ohm Max	3.804Ohm Max	135mOhm Max
Shielding	Unshielded	Unshielded	Unshielded	Unshielded	Unshielded
Ratings	-	-	-	-	-
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C
Mounting Type	Surface Mount	Surface Mount	Surface Mount	Surface Mount	Surface Mount
Size / Dimension	0.450" L x 0.450" W (11.43mm x 11.43mm)	0.550" L x 0.550" W (13.97mm x 13.97mm)	0.550" L x 0.550" W (13.97mm x 13.97mm)	0.450" L x 0.450" W (11.43mm x 11.43mm)	0.550" L x 0.550" W (13.97mm x 13.97mm)
Height	0.235" (5.97mm)	0.250" (6.35mm)	0.250" (6.35mm)	0.235" (5.97mm)	0.250" (6.35mm)
