AUO B116XAN04.0 HW8A

Name: B116XAN04.0 HW8A
Brand: AUO
SKU: B116XAN04.0 HW8A
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: B116XAN04.0 HW8A

Manufacturer:: AUO

Category:: TFT-LCD Panel

Package:

Description:: AUO 11.6" IPS LCM 1366×768 220nits WLED eDP

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

Product Details

B116XAN04.0 HW8A Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: AUO

Panel Size:: 11.6"

TNVAIPS:: IPS

Resolution:: 1366×768

CR:: 1900/2/2 8:01:00

Viewing Angle:: 85/85/85/85

Colors:: 262K

Outline Size:: 278(W)×168(H)×3(D)

Treatment:: Antiglare, Hard coating (3H)

Brightness:: 220 (Typ.)(cd/m²)

Contrast Ratio:: 800 : 1 (Typ.) (TM)

View Direction:

Viewing Angle:: 85/85/85/85 (Typ.)(CR≥10)

Response Time:: 27 (Typ.)(Tr+Td) ms

Best View on:: Symmetry

Work Mode:: AHVA, Normally Black, Transmissive

Glass Thickness:

Transmissivity:

Color Depth:: 262K 50% NTSC

Mass:

Used for:

Touch Screen:: Without

Refresh Rate:: 60Hz

Part Number	B116XAN04.2	B116XAN04.1	B116XAN04.3	B116XAN04.0 HW0A	B116XAN04.0 HW7A
Manufacturer	AUO	AUO	AUO	AUO	AUO
Panel Size	11.6"	11.6"	11.6"	11.6"	11.6"
TNVAIPS	IPS	IPS	IPS	IPS	IPS
Resolution	1366×768	1366×768	1366×768	1366×768	1366×768
CR	1900/2/2 8:01:00	1900/2/2 8:01:00	1900/2/2 8:01:00	1900/2/2 8:01:00	1900/2/2 8:01:00
Viewing Angle	85/85/85/85	85/85/85/85	85/85/85/85	85/85/85/85	85/85/85/85
Colors	262K	262K	262K	262K	262K
Outline Size	268.02 × 168.02 × 3.2 (H×V×D)	268(W)×168(H) ×3(D) mm	278(W)×168.89(H) ×3(D) mm	278 × 168 × 3 (H×V×D)	278(W)×168(H) ×3(D) mm
Treatment	Glare (Haze 0%)	Antiglare, Hard coating (3H)	Hard coating (3H)	Antiglare, Hard coating (3H)	Antiglare, Hard coating (3H)
Brightness	235 cd/m² (Typ.)	220 cd/m² (Typ.)	220 cd/m² (Typ.)	220 cd/m² (Typ.)	220 cd/m² (Typ.)
Contrast Ratio	800 : 1 (Typ.) (TM)	800:1 (Typ.) (TM)	800:1 (Typ.) (TM)	800 : 1 (Typ.) (TM)	800:1 (Typ.) (TM)
View Direction
Viewing Angle	85/85/85/85 (Typ.)(CR≥10) (Left / Right / Up / Down)	85/85/85/85 (Typ.)(CR≥10) (Left / Right / Up / Down)	85/85/85/85 (Typ.)(CR≥10)	85/85/85/85 (Typ.)(CR≥10) (Left / Right / Up / Down)	85/85/85/85 (Typ.)(CR≥10)
Response Time	27 (Typ.)(Tr+Td) ms	27 (Typ.)(Tr+Td)	27 (Typ.)(Tr+Td)	27 (Typ.)(Tr+Td) ms	27 (Typ.)(Tr+Td)
Best View on	Symmetry	Symmetry	Symmetry	Symmetry	Symmetry
Work Mode	AHVA, Normally Black, Transmissive	AHVA, Normally Black, Transmissive	AHVA, Normally Black, Transmissive	AHVA, Normally Black, Transmissive	AHVA, Normally Black, Transmissive
Glass Thickness
Transmissivity
Color Depth	262K 50% NTSC	262K 50% NTSC	262K 50% NTSC	262K 50% NTSC	262K 50% NTSC
Mass
Used for	Laptop	Laptop		Laptop
Touch Screen	Without	Without	Without	Without	Without
Refresh Rate	60Hz	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz	60Hz ([Panelook copyright, copy is strictly prohibited] 120Hz (60HZ Input) : Embedded MEMC Circuit 120Hz+120Hz : 120Hz Panel+120Hz Backlight 240Hz (60HZ Input) : Embedded MEMC Circuit)	60Hz
