Delevan 6052-036
- Part No.:
- 6052-036
- Manufacturer:
- Delevan
- Category:
- Power Transformers
- Package:
- Description:
- PWR XFMR LAMINATED 6VA TH
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
6052-036 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Delevan
- Series:
- 6052
- Packaging:
- Bulk
- Product Status:
- Obsolete
- Type:
- Laminated Core
- Voltage - Primary:
- 115V, 230V
- Voltage - Secondary (Full Load):
- -
- Current - Output (Max):
- -
- Primary Winding(s):
- Dual
- Secondary Winding(s):
- Dual
- Center Tap:
- No
- Power - Max:
- -
- Mounting Type:
- Through Hole
- Termination Style:
- PC Pin
- Size / Dimension:
- 47.62mm L x 39.68mm W
- Height - Seated (Max):
- 21.59mm
- Voltage - Isolation:
- 1500Vrms
- Weight:
- -
| Image |  |
 |
|
|
|
| Part Number | 6052R-024 | 6052-010 | 6052-012 | 6052-016 | 6052-020 |
| Manufacturer | Delevan | Delevan | Delevan | Delevan | Delevan |
| Series | 6052R | 6052 | 6052 | 6052 | 6052 |
| Packaging | Bulk | Bulk | Bulk | Bulk | Bulk |
| Product Status | Active | Obsolete | Obsolete | Obsolete | Obsolete |
| Type | Laminated Core | Laminated Core | Laminated Core | Laminated Core | Laminated Core |
| Voltage - Primary | 115V, 230V | 115V, 230V | 115V, 230V | 115V, 230V | 115V, 230V |
| Voltage - Secondary (Full Load) | Parallel 12V, Series 24V | Parallel 5V, Series 10V | Parallel 6.3V, Series 12.6V | Parallel 8V, Series 16V | Parallel 10V, Series 20V |
| Current - Output (Max) | Parallel 500mA, Series 250mA | Parallel 1.2A, Series 600mA | Parallel 900mA, Series 450mA | Parallel 700mA, Series 350mA | Parallel 600mA, Series 300mA |
| Primary Winding(s) | Dual | Dual | Dual | Dual | Dual |
| Secondary Winding(s) | Dual | Dual | Dual | Dual | Dual |
| Center Tap | No | No | No | No | No |
| Power - Max | 6VA | 6VA | 6VA | 6VA | 6VA |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Termination Style | PC Pin | PC Pin | PC Pin | PC Pin | PC Pin |
| Size / Dimension | 34.93mm L x 28.58mm W | 34.93mm L x 28.58mm W | 34.93mm L x 28.58mm W | 34.93mm L x 28.58mm W | 34.93mm L x 28.58mm W |
| Height - Seated (Max) | 23.80mm | 23.80mm | 23.80mm | 23.80mm | 23.80mm |
| Voltage - Isolation | 1500Vrms | 1500Vrms | 1500Vrms | 1500Vrms | 1500Vrms |
| Weight | 0.438 lb (198.67 g) | 0.438 lb (198.67 g) | 0.438 lb (198.67 g) | 0.438 lb (198.67 g) | 0.438 lb (198.67 g) |
