Littelfuse Inc. TSL250-080F-2

Product attributes

Attribute value

Manufacturer:

Littelfuse Inc.

Package/Case:

2-SMD

Series:

PolySwitch®, TSL250

Packaging:

Tape & Reel (TR)

Product Status:

Active

Type:

Polymeric

Voltage - Max:

80V (250V Int)

Current - Hold (Ih) (Max):

80 mA

Current - Trip (It):

240 mA

Current - Max:

3 A

Time to Trip:

800 ms

Resistance - Initial (Ri) (Min):

5 Ohms

Resistance - Post Trip (R1) (Max):

20 Ohms

Resistance - 25°C (Typ):

-

Operating Temperature:

-40°C ~ 85°C

Grade:

-

Qualification:

-

Ratings:

-

Mounting Type:

Surface Mount

Size / Dimension:

0.287" L x 0.199" W (7.30mm x 5.05mm)

Height - Seated (Max):

-

Thickness (Max):

0.146" (3.70mm)

Lead Spacing:

-
