Vishay Semiconductor Opto Division TDSG5160
- Part No.:
- TDSG5160
- Manufacturer:
- Vishay Semiconductor Opto Division
- Category:
- LED Character and Numeric
- Package:
- 10-DIP (0.600", 15.24mm)
- Datasheet:
-
TDSG5160.pdf
- Description:
- DISPLAY 7SEG 0.51" SGL GRN 10DIP
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
TDSG5160 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Vishay Semiconductor Opto Division
- Series:
- TDS.51
- Package/Case:
- 10-DIP (0.600", 15.24mm)
- Packaging:
- Tube
- Product Status:
- Active
- Display Format:
- -
- Number of Characters:
- 1
- Size / Dimension:
- 0.689" H x 0.482" W x 0.252" D (17.50mm x 12.25mm x 6.40mm)
- Digit/Alpha Size:
- 0.51" (13.00mm)
- Display Type:
- 7-Segment
- Common Pin:
- Common Cathode
- Color:
- Green
- Voltage - Forward (Vf) (Typ):
- 2.4V
- Current - Test:
- 20mA
- Millicandela Rating:
- 9.5mcd
- Wavelength - Peak:
- 565nm
- Power Dissipation (Max):
- 550mW
| Image |  |
|
 |
| Part Number | TDSG5160 | TDSG5160-N | TDSG5160-MN |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division |
| Series | TDS.51 | TDS.51 | TDS.51 |
| Package/Case | 10-DIP (0.600", 15.24mm) | 10-DIP (0.600", 15.24mm) | 10-DIP (0.600", 15.24mm) |
| Packaging | Tube | Tube | Bulk |
| Product Status | Active | Active | Active |
| Display Format | - | - | - |
| Number of Characters | 1 | 1 | 1 |
| Size / Dimension | 0.689" H x 0.482" W x 0.252" D (17.50mm x 12.25mm x 6.40mm) | 0.689" H x 0.482" W x 0.252" D (17.50mm x 12.25mm x 6.40mm) | 0.689" H x 0.482" W x 0.252" D (17.50mm x 12.25mm x 6.40mm) |
| Digit/Alpha Size | 0.51" (13.00mm) | 0.51" (13.00mm) | 0.51" (13.00mm) |
| Display Type | 7-Segment | 7-Segment | 7-Segment |
| Common Pin | Common Cathode | Common Cathode | Common Cathode |
| Color | Green | Green | Green |
| Voltage - Forward (Vf) (Typ) | 2.4V | 2.4V | 2.4V |
| Current - Test | 20mA | 20mA | 20mA |
| Millicandela Rating | 9.5mcd | 14mcd | 14mcd |
| Wavelength - Peak | 565nm | 565nm | 565nm |
| Power Dissipation (Max) | 550mW | 550mW | 550mW |
