Amgis, LLC SH50F-3.0-47
- Part No.:
- SH50F-3.0-47
- Manufacturer:
- Amgis, LLC
- Category:
- Fixed Inductors
- Package:
- Radial, Vertical Cylinder, 4 Leads
- Datasheet:
-
SH50F-3.0-47.pdf
- Description:
- FIXED IND 47UH 3A 50 MOHM TH
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
SH50F-3.0-47 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Amgis, LLC
- Series:
- SH50
- Package/Case:
- Radial, Vertical Cylinder, 4 Leads
- Packaging:
- Tray
- Product Status:
- Active
- Type:
- Toroidal
- Material - Core:
- Iron Powder
- Inductance:
- 47 µH
- Tolerance:
- ±20%
- Current Rating (Amps):
- 3 A
- Current - Saturation (Isat):
- -
- Shielding:
- Unshielded
- DC Resistance (DCR):
- 50mOhm Max
- Q @ Freq:
- -
- Frequency - Self Resonant:
- -
- Ratings:
- -
- Operating Temperature:
- -40°C ~ 125°C
- Inductance Frequency - Test:
- 10 kHz
- Features:
- -
- Mounting Type:
- Through Hole
- Supplier Device Package:
- -
- Size / Dimension:
- 0.669" Dia (17.00mm)
- Height - Seated (Max):
- 0.492" (12.50mm)
| Image |  |
 |
 |
 |
 |
| Part Number | SH50F-3.0-47 | SH50F-1.4-220 | SH50F-0.9-330 | SH50F-0.85-680 | SH50F-0.90-330 |
| Manufacturer | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| Series | SH50 | SH50 | SH50 | SH50 | SH50 |
| Package/Case | Radial, Vertical Cylinder, 4 Leads | Radial, Vertical Cylinder, 4 Leads | Radial, Vertical Cylinder, 4 Leads | Radial, Vertical Cylinder, 4 Leads | Horizontal, 4 PC Pin |
| Packaging | Tray | Tray | Tray | Tray | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| Type | Toroidal | Toroidal | Toroidal | Toroidal | Toroidal |
| Material - Core | Iron Powder | Iron Powder | Iron Powder | Iron Powder | - |
| Inductance | 47 µH | 220 µH | 330 µH | 680 µH | 302 µH |
| Tolerance | ±20% | ±20% | ±20% | ±20% | ±20% |
| Current Rating (Amps) | 3 A | 1.4 A | 900 mA | 850 mA | 900 mA |
| Current - Saturation (Isat) | - | - | - | - | - |
| Shielding | Unshielded | Unshielded | Unshielded | Unshielded | Unshielded |
| DC Resistance (DCR) | 50mOhm Max | 380mOhm Max | 740mOhm Max | 1.25Ohm Max | 740mOhm Max |
| Q @ Freq | - | - | - | - | - |
| Frequency - Self Resonant | - | - | - | - | - |
| Ratings | - | - | - | - | - |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Inductance Frequency - Test | 10 kHz | 10 kHz | 10 kHz | 10 kHz | 10 kHz |
| Features | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Supplier Device Package | - | - | - | - | Horizontal, 4 PC Pin |
| Size / Dimension | 0.669" Dia (17.00mm) | 0.669" Dia (17.00mm) | 0.669" Dia (17.00mm) | 0.669" Dia (17.00mm) | 0.689" L x 0.669" W (17.50mm x 17.00mm) |
| Height - Seated (Max) | 0.492" (12.50mm) | 0.492" (12.50mm) | 0.492" (12.50mm) | 0.492" (12.50mm) | 0.492" (12.50mm) |
