Microchip Technology PIC16LF1518-I/SS
- Part No.:
- PIC16LF1518-I/SS
- Manufacturer:
- Microchip Technology
- Category:
- Microcontrollers
- Package:
- 28-SSOP (0.209", 5.30mm Width)
- Description:
- IC MCU 8BIT 28KB FLASH 28SSOP
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Product Details
PIC16LF1518-I/SS - 8-bit Low-Power Microcontroller (nanoWatt XLP, 20-TSSOP)
PIC16LF1518-I/SS is a low-power 8-bit microcontroller from Microchip Technology, based on the enhanced mid-range PIC architecture. It integrates nanoWatt XLP technology for ultra-low power consumption, making it ideal for battery-powered and energy-sensitive embedded systems.
This page provides engineering reference and selection guidance. Always verify parameters using the official Microchip datasheet before final design.
Overview
PIC16LF1518-I/SS is part of the PIC16LF1xxx family, designed for applications requiring low power consumption and flexible peripheral integration. It features integrated analog and digital peripherals, including ADC, comparators, PWM modules, and communication interfaces.
With support for operation at low supply voltages and multiple power-saving modes, this MCU is well-suited for IoT nodes, portable devices, and industrial control systems. Its internal oscillator and configurable logic reduce external component count, simplifying system design.
Key Advantages
nanoWatt XLP technology enables long battery life in portable designs.
Includes ADC, PWM, comparators, and communication modules.
Internal oscillator reduces need for external components.
20-pin TSSOP suitable for space-constrained PCB designs.
Feature Summary
1.8V to 3.6V low-voltage operation.
Up to 28KB Flash program memory.
ADC, PWM, timers, comparators, and EUSART/I²C/SPI.
Multiple sleep and idle modes for energy savings.
Package & Footprint
The PIC16LF1518-I/SS is available in a 20-pin TSSOP surface-mount package, ideal for compact embedded designs and high-density PCB layouts.
(replace with actual package image)
- Use recommended PCB footprint for reliable soldering.
- Ensure proper decoupling capacitors near VDD pins.
- Follow Microchip layout guidelines for analog performance.
Pin Functions
The PIC16LF1518-I/SS includes GPIO, power, and communication pins typical of PIC microcontrollers.
Key Specifications
| Core | 8-bit PIC MCU |
|---|---|
| Operating Voltage | 1.8V – 3.6V |
| Flash Memory | Up to 28KB |
| RAM | Up to 2KB |
| Package | 20-TSSOP |
| Peripherals | ADC, PWM, Timers, Comparator |
| Communication | USART, SPI, I²C |
| Operating Temperature | -40°C to +85°C |
| Base Product | PIC16LF1518 |
Equivalent
Similar microcontrollers include:
- PIC16LF1517-I/SS – Microchip, lower memory variant
- PIC16F1934-I/PT – Microchip, similar peripherals with different package
- ATmega328P-AU – Microchip (Atmel), widely used 8-bit MCU alternative
Check pin compatibility and firmware migration requirements before substitution.
Manufacturer Information
Microchip Technology is a leading provider of microcontrollers, analog, and embedded control solutions.
- Strength: MCU, analog ICs, embedded systems
- Markets: Industrial, automotive, IoT
- Resources: MPLAB IDE, development tools, documentation
Applications
Typical applications include:
IoT Devices
Low-power sensor nodes and smart devices.
Portable Electronics
Battery-powered consumer products.
Industrial Control
Embedded control and monitoring systems.
Home Automation
Smart home control modules.
Quality & Authenticity
- Full traceability and supplier verification
- ESD-safe storage and handling
- Support for CoC, RoHS documentation
FAQ
Is PIC16LF1518 suitable for low-power applications?
Can it run on 3.3V?
Disclaimer
PIC16LF1518-I/SS Information
- Specifications
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Microchip Technology
- Package/Case:
- 28-SSOP (0.209", 5.30mm Width)
- Series:
- PIC® XLP™ 16F
- Packaging:
- Tube
- Product Status:
- Active
- Programmable:
- Not Verified
- Core Processor:
- PIC
- Core Size:
- 8-Bit
- Speed:
- 20MHz
- Connectivity:
- I2C, LINbus, SPI, UART/USART
- Peripherals:
- Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O:
- 25
- Program Memory Size:
- 28KB (16K x 14)
- Program Memory Type:
- FLASH
- EEPROM Size:
- -
- RAM Size:
- 1K x 8
- Voltage - Supply (Vcc/Vdd):
- 1.8V ~ 3.6V
- Data Converters:
- A/D 17x10b
- Oscillator Type:
- Internal
- Operating Temperature:
- -40°C ~ 85°C (TA)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- Include Parts
- Popular Search
