Pasternack PE51FP1005-4
- Part No.:
- PE51FP1005-4
- Manufacturer:
- Pasternack
- Category:
- RF Antennas
- Package:
- Datasheet:
-
PE51FP1005-4.pdf
- Description:
- 8 DBI 902-960MHZ OMNI SMA
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
PE51FP1005-4 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Pasternack
- Series:
- -
- Packaging:
- Bag
- Product Status:
- Active
- RF Family/Standard:
- Cellular, General ISM, WiFi
- Frequency Group:
- UHF (300MHz ~ 1GHz)
- Frequency (Center/Band):
- 915MHz
- Frequency Range:
- 902MHz ~ 928MHz
- Antenna Type:
- Panel
- Number of Bands:
- 1
- VSWR:
- 1.5
- Return Loss:
- -
- Gain:
- 8dBi
- Power - Max:
- -
- Features:
- Cable - 1.2192m
- Termination:
- SMA Male
- Ingress Protection:
- -
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Wall Mount
- Height (Max):
- 1.200" (30.48mm)
- Applications:
- GSM, ISM, LPWAN, LoRA, WLAN
| Image |  |
 |
 |
 |
 |
| Part Number | PE51FP1005-3 | PE51FP1005-1 | PE51FP1005-2 | PE51FP1005 | PE51FP1005-4 |
| Manufacturer | Pasternack | Pasternack | Pasternack | Pasternack | Pasternack |
| Series | - | - | - | - | - |
| Packaging | Bag | Bag | Bag | Retail Package | Bag |
| Product Status | Active | Active | Active | Active | Active |
| RF Family/Standard | Cellular, General ISM, WiFi | Cellular, General ISM, WiFi | Cellular, General ISM, WiFi | Cellular, General ISM | Cellular, General ISM, WiFi |
| Frequency Group | UHF (300MHz ~ 1GHz) | UHF (300MHz ~ 1GHz) | UHF (300MHz ~ 1GHz) | UHF (300MHz ~ 1GHz) | UHF (300MHz ~ 1GHz) |
| Frequency (Center/Band) | 915MHz | 915MHz | 915MHz | 915MHz | 915MHz |
| Frequency Range | 902MHz ~ 928MHz | 902MHz ~ 928MHz | 902MHz ~ 928MHz | 902MHz ~ 928MHz | 902MHz ~ 928MHz |
| Antenna Type | Panel | Panel | Panel | Panel | Panel |
| Number of Bands | 1 | 1 | 1 | 1 | 1 |
| VSWR | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| Return Loss | - | - | - | - | - |
| Gain | 8dBi | 8dBi | 8dBi | 8dBi | 8dBi |
| Power - Max | - | - | - | - | - |
| Features | Cable - 1.2192m | Cable - 1.2192m | Cable - 1.2192m | Cable - 304.8mm | Cable - 1.2192m |
| Termination | RP-TNC Male | N Type Male | RP-SMA | N Type Female | SMA Male |
| Ingress Protection | - | - | - | - | - |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Mounting Type | Wall Mount | Wall Mount | Wall Mount | Bracket Mount | Wall Mount |
| Height (Max) | 1.200" (30.48mm) | 1.200" (30.48mm) | 1.200" (30.48mm) | 1.100" (27.94mm) | 1.200" (30.48mm) |
| Applications | GSM, ISM, LPWAN, LoRA, WLAN | GSM, ISM, LPWAN, LoRA, WLAN | GSM, ISM, LPWAN, LoRA, WLAN | GSM, IoT, ISM, LoRa, LPWAN, M2M, RFID, WLAN | GSM, ISM, LPWAN, LoRA, WLAN |
