Taoglas Limited PA.25A
- Part No.:
- PA.25A
- Manufacturer:
- Taoglas Limited
- Category:
- RF Antennas
- Package:
- Datasheet:
-
PA.25A.pdf
- Description:
- RF ANT 850MHZ/900MHZ CHIP SLD
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
PA.25A Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Taoglas Limited
- Series:
- Anam
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- RF Family/Standard:
- Cellular
- Frequency Group:
- Wide Band
- Frequency (Center/Band):
- 850MHz, 900MHz, 1.7GHz, 1.8GHz, 1.9GHz, 2.1GHz
- Frequency Range:
- 824MHz ~ 960MHz, 1.7GHz ~ 2.17GHz
- Antenna Type:
- Chip
- Number of Bands:
- 6
- VSWR:
- 3
- Return Loss:
- -6.4dB, -12.7dB, -10.8dB, -13.5dB
- Gain:
- 1.49dBi, 1.76dBi, 2.4dBi, 2.53dBi, 2.46dBi, 4.62dBi
- Power - Max:
- -
- Features:
- -
- Termination:
- Solder
- Ingress Protection:
- -
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Height (Max):
- 0.236" (6.00mm)
- Applications:
- CDMA, DCS, EDGE, GPRS, GSM, HSDPA, PCS, UMTS, WCDMA
| Image |  |
 |
 |
 |
 |
| Part Number | PA.26A | PA.25A | PA.710.A | PA.760.A | PA.711.A |
| Manufacturer | Taoglas Limited | Taoglas Limited | Taoglas Limited | Taoglas Limited | Taoglas Limited |
| Series | Anam | Anam | Warrior | - | Warrior |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Active | Active |
| RF Family/Standard | Cellular | Cellular | Cellular | Cellular, WiFi | Cellular |
| Frequency Group | Wide Band | Wide Band | Wide Band | Wide Band | Wide Band |
| Frequency (Center/Band) | 829MHz, 2.2GHz | 850MHz, 900MHz, 1.7GHz, 1.8GHz, 1.9GHz, 2.1GHz | 700MHz, 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz, 2.6GHz | 657.5MHz, 752MHz, 892MHz, 1.4725GHz, 1.955GHz, 2.59GHz, 3.4GHz, 5.5375GHz | 700MHz, 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz, 2.6GHz |
| Frequency Range | 698MHz ~ 960MHz, 1.71GHz ~ 2.69GHz | 824MHz ~ 960MHz, 1.7GHz ~ 2.17GHz | 698MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.4GHz, 2.49GHz ~ 2.69GHz | 617MHz ~ 698MHz, 698MHz ~ 806MHz, 824MHz ~ 960MHz, 1.427GHz ~ 1.518GHz, 1.71GHz ~ 2.2GHz, 2.49GHz ~ 2.69GHz, 3.3GHz ~ 3.5GHz, 5.15GHz ~ 5.925GHz | 698MHz ~ 960MHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.4GHz, 2.49GHz ~ 2.69GHz |
| Antenna Type | PCB Trace | Chip | Chip | Chip | Chip |
| Number of Bands | 2 | 6 | 4 | 8 | 4 |
| VSWR | 3.5 | 3 | 3 | - | 3 |
| Return Loss | - | -6.4dB, -12.7dB, -10.8dB, -13.5dB | - | - | - |
| Gain | 3.9dBi | 1.49dBi, 1.76dBi, 2.4dBi, 2.53dBi, 2.46dBi, 4.62dBi | 1dBi, 3.2dBi, 3.5dBi, 3.5dBi | -0.7dBi, 0.5dBi, 1dBi, -0.5dBi, 3.4dBi, 2.9dBi, 4.3dBi, 3dBi | 1.0dBi, 2.9dBi, 4.1dBi, 2.8dBi |
| Power - Max | 5 W | - | 5 W | - | 5 W |
| Features | - | - | - | - | - |
| Termination | Solder | Solder | Solder | SMA Female | Solder |
| Ingress Protection | - | - | - | - | - |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Height (Max) | 0.236" (6.00mm) | 0.236" (6.00mm) | 0.197" (5.00mm) | 0.197" (5.00mm) | 0.197" (5.00mm) |
| Applications | LTE | CDMA, DCS, EDGE, GPRS, GSM, HSDPA, PCS, UMTS, WCDMA | CDMA, GSM, LTE, UMTS | LTE, Wi-Fi | CDMA, DCS, EDGE, GPRS, GSM, IMT, LTE, PCS, UMTS, WCDMA |
