Analog Devices Inc./Maxim Integrated DS28C36BQ+T
- Part No.:
- DS28C36BQ+T
- Manufacturer:
- Analog Devices Inc./Maxim Integrated
- Category:
- Specialized ICs
- Package:
- 6-WDFN Exposed Pad
- Description:
- IC AUTHENTICATION CHIP 6TDFN
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Product Details
DS28C36BQ+T - Analog Devices DeepCover® Secure Authenticator
The DS28C36BQ+T is a high-security DeepCover® Secure Authenticator from Analog Devices. It integrates FIPS 202-compliant SHA-3 and ECDSA-P256 cryptographic engines to provide a robust hardware-based root-of-trust. Housed in a compact TDFN-6 package, it is designed for secure peripheral authentication, secure boot, and data integrity verification in industrial and medical applications.
Product Overview
The DS28C36BQ+T provides comprehensive security by combining a high-speed ECDSA-P256 engine with SHA-3 for secure communication. It features nonvolatile memory, two configurable GPIOs, and a secure internal storage mechanism for public keys, making it an ideal choice for protecting intellectual property and verifying system authenticity.
About Analog Devices
Analog Devices, Inc. (ADI) is a global leader in high-performance analog technology, specializing in signal processing and industrial-grade security and connectivity solutions.
Key Advantages
FIPS-compliant cryptographic engine.
Fast and secure data integrity checking.
Protected nonvolatile memory for keys.
Two pins for flexible peripheral control.
Package & Mechanical Details
Compact TDFN-6 (2.5mm x 3.5mm) for high-density mounting.
- Industrial Temp: -40°C to +85°C
- RoHS: Compliant
Pin Functions & Terminal Map
Supports standard 1-Wire interface for power and communication, along with dedicated GPIOs for external device control.
Technical Specifications
| Part Number | DS28C36BQ+T |
|---|---|
| Manufacturer | Analog Devices |
| Crypto Engines | ECDSA, SHA-3 |
Equivalent & Replacement Guide
Typical Applications
Peripheral Authentication
Secure Boot Verification
Quality & Authenticity
Industrial grade quality standards, sourced via authorized Analog Devices distribution channels.
Frequently Asked Questions
Does it support secure boot?
Yes, it is designed for verifying system integrity and code signature.Is the device field-programmable?
Includes protected nonvolatile memory for custom key storage.Disclaimer
Technical details are for reference only. Consult official Analog Devices documentation for design-in qualification.
DS28C36BQ+T Information
- Specifications
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Analog Devices Inc./Maxim Integrated
- Series:
- DeepCover®
- Package/Case:
- 6-WDFN Exposed Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Programmable:
- Not Verified
- Type:
- Secure Authenticator
- Applications:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 6-TDFN (3x3)
- Grade:
- -
- Qualification:
- -
- Include Parts
