TDK Corporation DPX205850DT-4055A1
- Part No.:
- DPX205850DT-4055A1
- Manufacturer:
- TDK Corporation
- Category:
- RF Multiplexers
- Package:
- 0805 (2012 Metric), 6 PC Pad
- Datasheet:
-
DPX205850DT-4055A1.pdf
- Description:
- RF DIPLEXER 1345MZ/4.125GHZ 0805
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
DPX205850DT-4055A1 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- TDK Corporation
- Series:
- DPX
- Package/Case:
- 0805 (2012 Metric), 6 PC Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Type:
- Diplexer
- Frequency Bands (Low / High):
- 700MHz ~ 1.99GHz / 2.4GHz ~ 5.85GHz
- Low Band Attenuation (min / max dB):
- 13.00dB / 28.00dB
- High Band Attenuation (min / max dB):
- 15.00dB / 21.00dB
- Return Loss (Low Band / High Band):
- 9.5dB / 9.5dB
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
| Image |  |
 |
 |
 |
 |
| Part Number | DPX205850DT-4054B5 | DPX205850DT-4054B1 | DPX205850DT-4055A1 | DPX205850DT-4152B2 | DPX205850DT-9043B1BR |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| Series | DPX | DPX | DPX | DPX | DPX |
| Package/Case | 0805 (2012 Metric), 6 PC Pad | 0805 (2012 Metric), 6 PC Pad | 0805 (2012 Metric), 6 PC Pad | 0805 (2012 Metric), 6 PC Pad | 0805 (2012 Metric), 6 PC Pad |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Active | Active |
| Type | Diplexer | Diplexer | Diplexer | Diplexer | Diplexer |
| Frequency Bands (Low / High) | 698MHz ~ 2.17GHz / 2.4GHz ~ 5.85GHz | 800MHz ~ 2.17GHz / 2.4GHz ~ 5.85GHz | 700MHz ~ 1.99GHz / 2.4GHz ~ 5.85GHz | 174MHz ~ 1.58GHz / 2.4GHz ~ 5.85GHz | 2.4GHz ~ 2.5GHz / 5.15GHz ~ 5.85GHz |
| Low Band Attenuation (min / max dB) | 25.00dB / 36.00dB | 10.00dB / 36.00dB | 13.00dB / 28.00dB | 13.00dB / 28.00dB | 23.00dB / 39.10dB |
| High Band Attenuation (min / max dB) | 12.00dB / 23.00dB | 12.00dB / 24.00dB | 15.00dB / 21.00dB | 9.00dB / 28.00dB | 20.00dB / 31.20dB |
| Return Loss (Low Band / High Band) | 10.0dB / 10.0dB | 10.0dB / 10.0dB | 9.5dB / 9.5dB | 12.0dB / 28.0dB | 10.0dB / 10.0dB |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
