TDK Corporation DPX165850DT-8032A1
- Part No.:
- DPX165850DT-8032A1
- Manufacturer:
- TDK Corporation
- Category:
- RF Multiplexers
- Package:
- 0603 (1608 Metric), 4 PC Pad
- Datasheet:
-
DPX165850DT-8032A1.pdf
- Description:
- RF DIPLEXER 0603 4 PC PAD
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
DPX165850DT-8032A1 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- TDK Corporation
- Series:
- DPX
- Package/Case:
- 0603 (1608 Metric), 4 PC Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Type:
- Diplexer
- Frequency Bands (Low / High):
- -
- Low Band Attenuation (min / max dB):
- 20.00dB / 24.00dB
- High Band Attenuation (min / max dB):
- -
- Return Loss (Low Band / High Band):
- 9.5dB / 9.5dB
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
| Image |  |
 |
 |
 |
 |
| Part Number | DPX165850DT-8032A1 | DPX165850DT-8086A2 | DPX165850DT-8085D3 | DPX165850DT-8117A1 | DPX165850DT-8040B1 |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| Series | DPX | - | - | DPX | DPX |
| Package/Case | 0603 (1608 Metric), 4 PC Pad | 0603 (1608 Metric), 6 PC Pad | 0603 (1608 Metric), 6 PC Pad | 0603 (1608 Metric), 4 PC Pad | 0603 (1608 Metric), 6 PC Pad |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Active | Active |
| Type | Diplexer | Diplexer | Diplexer | Diplexer | Diplexer |
| Frequency Bands (Low / High) | - | 698MHz ~ 2.69GHz / 3.3GHz ~ 5.85GHz | 698MHz ~ 2.69GHz / 5.15GHz ~ 5.85GHz | 2.4GHz ~ 2.5GHz / 4.9GHz ~ 5.85GHz | 2.4GHz ~ 2.5GHz / 4.9GHz ~ 5.85GHz |
| Low Band Attenuation (min / max dB) | 20.00dB / 24.00dB | 20.00dB / 23.80db | 35.00dB / 41.00dB | 15.00dB / 19.00dB | 30.00dB / 46.00dB |
| High Band Attenuation (min / max dB) | - | 18.00dB / 23.40db | 40.00dB / 43.00dB | 20.00dB / 24.00dB | 30.00dB / 44.00dB |
| Return Loss (Low Band / High Band) | 9.5dB / 9.5dB | - | - | 21.0dB / 20.0dB | 10.0dB / 9.0dB |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
