TDK Corporation DPX162500DT-8028A1
- Part No.:
- DPX162500DT-8028A1
- Manufacturer:
- TDK Corporation
- Category:
- RF Multiplexers
- Package:
- 0603 (1608 Metric)
- Datasheet:
-
DPX162500DT-8028A1.pdf
- Description:
- RF DIPLEXER 1.575/2.45GHZ 0603
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
DPX162500DT-8028A1 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- TDK Corporation
- Series:
- DPX
- Package/Case:
- 0603 (1608 Metric)
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Type:
- Diplexer
- Frequency Bands (Low / High):
- 1.572GHz ~ 1.578GHz / 2.4GHz ~ 2.5GHz
- Low Band Attenuation (min / max dB):
- 13.00dB / 22.40dB
- High Band Attenuation (min / max dB):
- 22.00dB / 36.60dB
- Return Loss (Low Band / High Band):
- 14.0dB / 14.0dB
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
| Image |  |
 |
 |
 |
| Part Number | DPX162500DT-8028A1 | DPX162500DT-8128A1 | DPX162500DT-8014A1 | DPX162500DT-8114C1 |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| Series | DPX | DPX | DPX | DPX |
| Package/Case | 0603 (1608 Metric) | 0603 (1608 Metric), 6 PC Pad | 0603 (1608 Metric), 4 PC Pad | 0603 (1608 Metric), 4 PC Pad |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Not For New Designs |
| Type | Diplexer | Diplexer | Diplexer | Diplexer |
| Frequency Bands (Low / High) | 1.572GHz ~ 1.578GHz / 2.4GHz ~ 2.5GHz | - | 1.565GHz ~ 1.585GHz / 2.4GHz ~ 2.5GHz | 1.565GHz ~ 1.585GHz / 2.4GHz ~ 2.5GHz |
| Low Band Attenuation (min / max dB) | 13.00dB / 22.40dB | - | 20.00dB / - | 20.00dB / 25.80dB |
| High Band Attenuation (min / max dB) | 22.00dB / 36.60dB | - | 20.00dB / - | 20.00dB / 27.90dB |
| Return Loss (Low Band / High Band) | 14.0dB / 14.0dB | - | 9.5dB / 9.5dB | 9.54dB / 9.54dB |
| Grade | - | - | - | - |
| Qualification | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
