PUI Audio, Inc. AS02008MR-5-R
- Part No.:
- AS02008MR-5-R
- Manufacturer:
- PUI Audio, Inc.
- Category:
- Speakers
- Package:
- Datasheet:
-
AS02008MR-5-R.pdf
- Description:
- SPEAKER 8OHM 500MW TOP PORT 86DB
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
AS02008MR-5-R Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- PUI Audio, Inc.
- Series:
- AS
- Packaging:
- Tray
- Product Status:
- Active
- Technology:
- Magnetic
- Type:
- General Purpose
- Frequency Range:
- 500 Hz ~ 4 kHz
- Frequency - Self Resonant:
- 500Hz
- Impedance:
- 8 Ohms
- Efficiency - dBA:
- 86.00
- Efficiency - Testing:
- 100mW/100mm
- Efficiency - Type:
- Sound Pressure Level (SPL)
- Power - Rated:
- 500 mW
- Power - Max:
- 800 mW
- Port Location:
- Top
- Shape:
- Round
- Material - Cone:
- Polyester, Polyethylene Terephthalate (PET)
- Material - Magnet:
- Nd-Fe-B
- Ingress Protection:
- -
- Ratings:
- -
- Termination:
- Solder Pads
- Size / Dimension:
- 0.787" Dia (20.00mm)
| Image |  |
 |
 |
|
 |
| Part Number | AS02008MR-R | AS02008MR-5-R | AS02008MR-7 | AS02008MR-HT-WP | AS02008MR-LW152-R |
| Manufacturer | PUI Audio, Inc. | PUI Audio, Inc. | PUI Audio, Inc. | PUI Audio, Inc. | PUI Audio, Inc. |
| Series | AS | AS | AS | AS | AS |
| Packaging | Tray | Tray | Bulk | Bulk | Tray |
| Product Status | Active | Active | Active | Active | Active |
| Technology | Magnetic | Magnetic | Magnetic | Magnetic | Magnetic |
| Type | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Frequency Range | 500 Hz ~ 4 kHz | 500 Hz ~ 4 kHz | 350 Hz ~ 6 kHz | 1 kHz ~ 20 kHz | 500 Hz ~ 4 kHz |
| Frequency - Self Resonant | 500Hz | 500Hz | 580Hz | 1kHz | 500Hz |
| Impedance | 8 Ohms | 8 Ohms | 8 Ohms | 8 Ohms | 8 Ohms |
| Efficiency - dBA | 86.00 | 86.00 | 71.00 | 80.00 | 86.00 |
| Efficiency - Testing | 100mW/100mm | 100mW/100mm | 300mW/500mm | 1W/100mm | 100mW/100mm |
| Efficiency - Type | Sound Pressure Level (SPL) | Sound Pressure Level (SPL) | Sensitivity | Sensitivity | Sound Pressure Level (SPL) |
| Power - Rated | 500 mW | 500 mW | 300 mW | 1.2 W | 500 mW |
| Power - Max | 800 mW | 800 mW | 500 mW | 1.5 W | 800 mW |
| Port Location | Top | Top | Top | Top | Top |
| Shape | Round | Round | Round | Round | Round |
| Material - Cone | Polyester, Polyethylene Terephthalate (PET) | Polyester, Polyethylene Terephthalate (PET) | Polyethylene Terephthalate (PET) | Polyethylene Naphthalate (PEN) | Polyester, Polyethylene Terephthalate (PET) |
| Material - Magnet | Nd-Fe-B | Nd-Fe-B | Nd-Fe-B | Nd-Fe-B | Nd-Fe-B |
| Ingress Protection | - | - | - | IPX5 | - |
| Ratings | - | - | - | - | IEC 60601-1-8 |
| Termination | Solder Pads | Solder Pads | None | None | Wire Leads |
| Size / Dimension | 0.787" Dia (20.00mm) | 0.787" Dia (20.00mm) | 0.787" Dia (20.00mm) | 0.787" Dia (20.00mm) | 0.787" Dia (20.00mm) |
- Include Parts
- Popular Search
The following parts include "AS02008MR-5-R" in Silicon Labs AS02008MR-5-R.
- Part Number
- Manufacturer
- Package
- Description
- PSR-28N08A-JQ Mallory Sonalert Products Inc. SPEAKER 8OHM 250MW TOP PORT 89DB
- SP-1504 Soberton Inc. SPEAKER 8OHM 800MW TOP PORT 93DB
- CDM-20008 Same Sky (Formerly CUI Devices) SPEAKER 8OHM 300MW TOP PORT 92DB
- CMS-15113-076S-67 Same Sky (Formerly CUI Devices) SPEAKER 6OHM 700MW TOP PORT 92DB
- SP-1609S Soberton Inc. SPEAKER 8OHM 700MW TOP PORT 92DB
- AS02008MR-R PUI Audio, Inc. SPEAKER 8OHM 500MW TOP PORT 86DB
- E-12041808 Soberton Inc. SPEAKER 8OHM 2W TOP PORT 87DB
- AS02008MR-5-R PUI Audio, Inc. SPEAKER 8OHM 500MW TOP PORT 86DB
- AR027150MR-2-R PUI Audio, Inc. SPEAKER 150OHM 15MW TOP PT 118DB
- AS01808AO-3-R PUI Audio, Inc. SPEAKER 8OHM 1W TOP PORT 94DB
