TE Connectivity Passive Product 2-2176547-1
- Part No.:
- 2-2176547-1
- Manufacturer:
- TE Connectivity Passive Product
- Category:
- Through Hole Resistors
- Package:
- Axial
- Description:
- RES 1K OHM 10% 1/2W AXIAL
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
2-2176547-1 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- TE Connectivity Passive Product
- Series:
- CBT, Neohm
- Packaging:
- Tape & Box (TB)
- Product Status:
- Obsolete
- Resistance:
- 1 kOhms
- Tolerance:
- ±10%
- Power (Watts):
- 0.5W, 1/2W
- Composition:
- Carbon Composition
- Features:
- Pulse Withstanding
- Temperature Coefficient:
- -
- Operating Temperature:
- -55°C ~ 125°C
- Supplier Device Package:
- Axial
- Size / Dimension:
- 0.094" Dia x 0.248" L (2.40mm x 6.30mm)
- Height - Seated (Max):
- -
- Number of Terminations:
- 2
- Failure Rate:
- -
| Image |  |
 |
|
|
|
| Part Number | 2-2176633-9 | 2176633-9 | 2-2176633-0 | 2176633-1 | 2-2176633-1 |
| Manufacturer | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product | TE Connectivity Passive Product |
| Series | SQ, CGS | SQ, CGS | SQ, CGS | SQ, CGS | SQ, CGS |
| Packaging | Bulk | Bulk | Bulk | Bulk | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| Resistance | 15 Ohms | 2.2 Ohms | 6.2 Ohms | 1 Ohms | 6.8 Ohms |
| Tolerance | ±5% | ±5% | ±5% | ±5% | ±5% |
| Power (Watts) | 10W | 10W | 10W | 10W | 10W |
| Composition | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound |
| Features | Cement Coated, Flame Proof, Moisture Resistant, Safety | Cement Coated, Flame Proof, Moisture Resistant, Safety | Cement Coated, Flame Proof, Moisture Resistant, Safety | Cement Coated, Flame Proof, Moisture Resistant, Safety | Cement Coated, Flame Proof, Moisture Resistant, Safety |
| Temperature Coefficient | ±300ppm/°C | ±300ppm/°C | ±300ppm/°C | ±300ppm/°C | ±300ppm/°C |
| Operating Temperature | -55°C ~ 250°C | -55°C ~ 250°C | -55°C ~ 250°C | -55°C ~ 250°C | -55°C ~ 250°C |
| Supplier Device Package | - | - | - | - | - |
| Size / Dimension | 0.787" L x 0.394" W (20.00mm x 10.00mm) | 0.787" L x 0.394" W (20.00mm x 10.00mm) | 0.787" L x 0.394" W (20.00mm x 10.00mm) | 0.787" L x 0.394" W (20.00mm x 10.00mm) | 0.787" L x 0.394" W (20.00mm x 10.00mm) |
| Height - Seated (Max) | 1.181" (30.00mm) | 1.181" (30.00mm) | 1.181" (30.00mm) | 1.181" (30.00mm) | 1.181" (30.00mm) |
| Number of Terminations | 2 | 2 | 2 | 2 | 2 |
| Failure Rate | - | - | - | - | - |
