Optex FA Z3D-100CN4
- Part No.:
- Z3D-100CN4
- Manufacturer:
- Optex FA
- Category:
- Photoelectric, Industrial
- Package:
- Datasheet:
-
Z3D-100CN4.pdf
- Description:
- SENSOR DIFFUSE 0-1M NPN M8
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Z3D-100CN4 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Optex FA
- Series:
- Z3
- Packaging:
- Box
- Product Status:
- Active
- Sensing Method:
- Reflective, Diffuse
- Sensing Distance:
- 0" ~ 39.37" (0m ~ 1m)
- Voltage - Supply:
- 10V ~ 30V
- Response Time:
- 500µs
- Output Configuration:
- NPN - Open Collector, Light-ON\Dark-ON
- Light Source:
- Red (632nm)
- Connection Method:
- Connector, M8
- Ingress Protection:
- IP67
- Cable Length:
- -
- Adjustment Type:
- Adjustable, 1-Turn Potentiometer
- Operating Temperature:
- -25°C ~ 55°C (TA)
| Image |  |
 |
 |
|
| Part Number | Z3D-100N | Z3D-100CN4 | Z3D-100P | Z3D-100CP4 |
| Manufacturer | Optex FA | Optex FA | Optex FA | Optex FA |
| Series | Z3 | Z3 | Z3 | Z3 |
| Packaging | Box | Box | Box | Box |
| Product Status | Active | Active | Active | Active |
| Sensing Method | Reflective, Diffuse | Reflective, Diffuse | Reflective, Diffuse | Reflective, Diffuse |
| Sensing Distance | 0" ~ 39.37" (0m ~ 1m) | 0" ~ 39.37" (0m ~ 1m) | 0" ~ 39.37" (0m ~ 1m) | 0" ~ 39.37" (0m ~ 1m) |
| Voltage - Supply | 10V ~ 30V | 10V ~ 30V | 10V ~ 30V | 10V ~ 30V |
| Response Time | 500µs | 500µs | 500µs | 500µs |
| Output Configuration | NPN - Open Collector, Light-ON\Dark-ON | NPN - Open Collector, Light-ON\Dark-ON | PNP - Open Collector, Light-ON\Dark-ON | PNP - Open Collector, Light-ON\Dark-ON |
| Light Source | Red (632nm) | Red (632nm) | Red (632nm) | Red (632nm) |
| Connection Method | Cable | Connector, M8 | Cable | Connector, M8 |
| Ingress Protection | IP67 | IP67 | IP67 | IP67 |
| Cable Length | 78.74" (2m) | - | 78.74" (2m) | - |
| Adjustment Type | Adjustable, 1-Turn Potentiometer | Adjustable, 1-Turn Potentiometer | Adjustable, 1-Turn Potentiometer | Adjustable, 1-Turn Potentiometer |
| Operating Temperature | -25°C ~ 55°C (TA) | -25°C ~ 55°C (TA) | -25°C ~ 55°C (TA) | -25°C ~ 55°C (TA) |
