TDK Corporation WT505090-10F2-A11-G1

Name: WT505090-10F2-A11-G1
Brand: TDK Corporation
SKU: WT505090-10F2-A11-G1
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: WT505090-10F2-A11-G1

Manufacturer:: TDK Corporation

Category:: Wireless Charging Coils

Package:

Datasheet:: WT505090-10F2-A11-G1.pdf

Description:: TX 1 COIL, 1 LYR 6.3UH

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

WT505090-10F2-A11-G1 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: TDK Corporation

Series:: WT

Packaging:: Bulk

Product Status:: Active

Function:: Transmitter

Type:: 1 Coil, 1 Layer

Inductance:: 6.3µH

Tolerance:: -

DC Resistance (DCR):: 60mOhm

Q @ Freq:: -

Current Rating (Amps):: -

Current - Saturation (Isat):: -

Frequency - Self Resonant:: -

Operating Temperature:: -

Size / Dimension:: 2.02" Dia x 0.13" H (51.4mm x 3.4mm)

Part Number	WT505090-10F2-A11-G1	WT505090-10F2-LP-G1	WT505090-10K2-A11-G	WT505090-20K2-A10-G	WT505090-10F2-LP-G
Manufacturer	TDK Corporation	TDK Corporation	TDK Corporation	TDK Corporation	TDK Corporation
Series	WT	WT	WT	WT	WT
Packaging	Bulk	Tray	Tray	Tray	Tray
Product Status	Active	Active	Not For New Designs	Active	Not For New Designs
Function	Transmitter	Transmitter	Transmitter	Transmitter	Transmitter
Type	1 Coil, 1 Layer	1 Coil, 1 Layer	1 Coil, 1 Layer	1 Coil, 2 Layer	1 Coil, 1 Layer
Inductance	6.3µH	6.3µH	6.3µH	24µH	6.3µH
Tolerance	-	-	-	-	-
DC Resistance (DCR)	60mOhm	60mOhm	60mOhm	100mOhm	60mOhm
Q @ Freq	-	-	-	-	-
Current Rating (Amps)	-	-	-	-	-
Current - Saturation (Isat)	-	-	-	-	-
Frequency - Self Resonant	-	-	-	-	-
Operating Temperature	-	-	-	-	-
Size / Dimension	2.02" Dia x 0.13" H (51.4mm x 3.4mm)	2.02" Dia x 0.13" H (51.4mm x 3.4mm)	1.97" Dia x 0.15" H (50.0mm x 3.8mm)	1.97" Dia x 0.15" H (50.0mm x 3.8mm)	1.97" Dia x 0.10" H (50.0mm x 2.5mm)
