TE Connectivity Linx RXD-315-KH
- Part No.:
- RXD-315-KH
- Manufacturer:
- TE Connectivity Linx
- Category:
- RF Receivers
- Package:
- 28-SMD, No Lead
- Datasheet:
-
RXD-315-KH.pdf
- Description:
- RF RECEIVER ASK/OOK 315MHZ
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
RXD-315-KH Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- TE Connectivity Linx
- Series:
- KH
- Package/Case:
- 28-SMD, No Lead
- Packaging:
- Tube
- Product Status:
- Obsolete
- Frequency:
- 315MHz
- Sensitivity:
- -102dBm
- Data Rate (Max):
- 5kbps
- Modulation or Protocol:
- ASK, OOK
- Applications:
- Garage Openers, RKE, Security Alarms
- Current - Receiving:
- 7mA
- Data Interface:
- PCB, Surface Mount
- Memory Size:
- -
- Antenna Connector:
- PCB, Surface Mount
- Features:
- Built-in Remote Control Decoder
- Voltage - Supply:
- 2.7V ~ 4.2V
- Operating Temperature:
- -30°C ~ 70°C
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- -
| Image |  |
 |
 |
 |
|
| Part Number | RXD-433-KH2 | RXD-418-KH2 | RXD-315-KH2 | RXD-315-KH | RXD-418-KH |
| Manufacturer | TE Connectivity Linx | TE Connectivity Linx | TE Connectivity Linx | TE Connectivity Linx | TE Connectivity Linx |
| Series | KH2 | KH2 | KH2 | KH | KH |
| Package/Case | 28-SMD, No Lead | 28-SMD, No Lead | 28-SMD, No Lead | 28-SMD, No Lead | 28-SMD, No Lead |
| Packaging | Tube | Tube | Tube | Tube | Tube |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Frequency | 433.92MHz | 418MHz | 315MHz | 315MHz | 418MHz |
| Sensitivity | -112dBm | -112dBm | -112dBm | -102dBm | -102dBm |
| Data Rate (Max) | 10kbps | 10kbps | 10kbps | 5kbps | 5kbps |
| Modulation or Protocol | ASK, OOK | ASK, OOK | ASK, OOK | ASK, OOK | ASK, OOK |
| Applications | Garage Openers, RKE, Security Alarms | Garage Openers, RKE, Security Alarms | Garage Openers, RKE, Security Alarms | Garage Openers, RKE, Security Alarms | Garage Openers, RKE, Security Alarms |
| Current - Receiving | 5.2mA | 5.2mA | 5.2mA | 7mA | 7mA |
| Data Interface | PCB, Surface Mount | PCB, Surface Mount | PCB, Surface Mount | PCB, Surface Mount | PCB, Surface Mount |
| Memory Size | - | - | - | - | - |
| Antenna Connector | PCB, Surface Mount | PCB, Surface Mount | PCB, Surface Mount | PCB, Surface Mount | PCB, Surface Mount |
| Features | Built-in Remote Control Decoder | Built-in Remote Control Decoder | Built-in Remote Control Decoder | Built-in Remote Control Decoder | Built-in Remote Control Decoder |
| Voltage - Supply | 2.7V ~ 3.6V | 2.7V ~ 3.6V | 2.7V ~ 3.6V | 2.7V ~ 4.2V | 2.7V ~ 4.2V |
| Operating Temperature | -30°C ~ 70°C | -30°C ~ 70°C | -30°C ~ 70°C | -30°C ~ 70°C | -30°C ~ 70°C |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | - | - | - | - | - |
