RECOM Power R1SE-0512/H2-R
- Part No.:
- R1SE-0512/H2-R
- Manufacturer:
- RECOM Power
- Category:
- DC DC Converters
- Package:
- 8-SMD Module, 5 Leads
- Description:
- DC DC CONVERTER 12V 1W
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Product Details
R1SE-0512/H2-R - 1W Isolated DC/DC Converter (5V to 12V, SIP/SMD)
R1SE-0512/H2-R is a compact isolated DC/DC converter module from RECOM, designed to provide reliable voltage conversion with galvanic isolation. It converts a 5V input to a regulated 12V output, making it ideal for industrial control, communication systems, and embedded power applications.
This page provides engineering-level product insight for selection and comparison. Always verify final design parameters using the official RECOM datasheet.
Overview
R1SE-0512/H2-R is part of RECOM's R1SE series of 1W isolated DC/DC converters. It integrates internal switching circuitry and transformer isolation, eliminating the need for complex external designs.
The module offers high isolation voltage, compact size, and stable output performance. It is optimized for space-constrained designs requiring reliable power conversion and noise isolation between circuits.
Key Advantages
Integrated transformer isolation reduces PCB space and simplifies power design.
Provides regulated output suitable for industrial and embedded applications.
Designed for long-term operation with robust thermal and electrical performance.
Minimal external components required, simplifying system design.
Feature Summary
1W isolated output.
5V nominal input.
12V regulated output.
Provides galvanic isolation between input and output.
Package & Footprint
The R1SE-0512/H2-R is available in a compact SIP/SMD module package, suitable for high-density PCB layouts.
- Keep input/output traces short to reduce noise.
- Place decoupling capacitors close to pins.
- Maintain isolation clearance in PCB layout.
Refer to the official datasheet for exact dimensions and footprint details.
Key Specifications
| Device Type | Isolated DC/DC Converter |
|---|---|
| Input Voltage | 5V |
| Output Voltage | 12V |
| Output Power | 1W |
| Isolation Voltage | Typically 1kVDC |
| Efficiency | Up to ~80% (typ.) |
| Package | SIP / SMD |
| Operating Temperature | -40°C to +85°C |
| Series | R1SE |
Equivalent
Comparable DC/DC modules include:
- F0512XT-1WR3 – Mornsun, 1W isolated DC/DC converter (5V to 12V)
- B0512XT-1WR3 – Mornsun, similar performance module with compact package
- F0512XT-1WR3-TR – Mornsun, tape & reel version for automated assembly
- B0512XT-1WR3-TR – Mornsun, alternative packaging option
Verify pin compatibility, efficiency, and isolation ratings before substitution.
Manufacturer Information
RECOM is a globally recognized manufacturer specializing in power conversion solutions, including AC/DC and DC/DC converters for industrial, medical, and IoT applications.
- Expertise: Power modules, converters, switching regulators
- Applications: Industrial automation, telecom, embedded systems
- Strength: High reliability and compact power solutions
Applications
Typical use cases include:
Industrial Control
Isolated power supply for control circuits.
Communication Systems
Power isolation in signal transmission equipment.
Embedded Systems
Compact power modules for MCU and logic circuits.
Instrumentation
Noise isolation for precision measurement systems.
Quality & Authenticity
- Original manufacturer sourcing
- Full traceability and quality inspection
- ESD-safe packaging and handling
FAQ
Is this module regulated or unregulated?
Does it require external components?
Disclaimer
R1SE-0512/H2-R Information
- Specifications
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- RECOM Power
- Series:
- ECONOLINE R1SE-H2 (1W)
- Package/Case:
- 8-SMD Module, 5 Leads
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Type:
- Isolated Module
- Number of Outputs:
- 1
- Voltage - Input (Min):
- 4.5V
- Voltage - Input (Max):
- 5.5V
- Voltage - Output 1:
- 12V
- Voltage - Output 2:
- -
- Voltage - Output 3:
- -
- Voltage - Output 4:
- -
- Current - Output (Max):
- 84mA
- Power (Watts):
- 1 W
- Voltage - Isolation:
- 2 kV
- Applications:
- ITE (Commercial)
- Features:
- -
- Operating Temperature:
- -40°C ~ 100°C
- Efficiency:
- 76%
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- -
- Control Features:
- -
- Approval Agency:
- -
- Standard Number:
- -
