Picker Components PC375-2C-24S4-X

Name: PC375-2C-24S4-X
Brand: Picker Components
SKU: PC375-2C-24S4-X
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: PC375-2C-24S4-X

Manufacturer:: Picker Components

Category:: Power Relays, Over 2 Amps

Package:

Datasheet:: PC375-2C-24S4-X.pdf

Description:: RELAY GEN PURPOSE DPDT 16A 24V

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

PC375-2C-24S4-X Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Picker Components

Series:: PC375

Packaging:: Tube

Product Status:: Active

Mounting Type:: Through Hole

Coil Voltage:: 24VDC

Contact Form:: DPDT (2 Form C)

Contact Rating (Current):: 8 A

Switching Voltage:: 380VAC, 110VDC - Max

Load - Max Switching:: 6080VA, 1760W

Coil Current:: 17.1 mA

Coil Type:: Non Latching

Features:: -

Termination Style:: PC Pin

Seal Rating:: Sealed - Fully

Coil Insulation:: Class F

Must Operate Voltage:: 16.8 VDC

Must Release Voltage:: 2.4 VDC

Operate Time:: 15 ms

Release Time:: 8 ms

Operating Temperature:: -40°C ~ 85°C

Contact Material:: Silver Tin Oxide (AgSnO)

Relay Type:: General Purpose

Grade:: -

Qualification:: -

Part Number	PC375-2C-24S4-X	PC375-2C-12S4-X	PC375-1C-12S1-X	PC375-1C-5S1-X	PC375-1C-24S3-X
Manufacturer	Picker Components	Picker Components	Picker Components	Picker Components	Picker Components
Series	PC375	PC375	PC375	PC375	PC375
Packaging	Tube	Tube	Tube	Tube	Tube
Product Status	Active	Active	Active	Active	Active
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Coil Voltage	24VDC	12VDC	12VDC	5VDC	24VDC
Contact Form	DPDT (2 Form C)	DPDT (2 Form C)	SPDT (1 Form C)	SPDT (1 Form C)	SPDT (1 Form C)
Contact Rating (Current)	8 A	8 A	16 A	16 A	16 A
Switching Voltage	380VAC, 110VDC - Max	380VAC, 110VDC - Max	380VAC, 110VDC - Max	380VAC, 110VDC - Max	380VAC, 110VDC - Max
Load - Max Switching	6080VA, 1760W	6080VA, 1760W	6080VA, 1760W	6080VA, 1760W	6080VA, 1760W
Coil Current	17.1 mA	34.2 mA	34.2 mA	82 mA	17.1 mA
Coil Type	Non Latching	Non Latching	Non Latching	Non Latching	Non Latching
Features	-	-	-	-	-
Termination Style	PC Pin	PC Pin	PC Pin	PC Pin	PC Pin
Seal Rating	Sealed - Fully	Sealed - Fully	Sealed - Fully	Sealed - Fully	Sealed - Fully
Coil Insulation	Class F	Class F	Class F	Class F	Class F
Must Operate Voltage	16.8 VDC	8.4 VDC	8.4 VDC	3.5 VDC	16.8 VDC
Must Release Voltage	2.4 VDC	1.2 VDC	1.2 VDC	0.5 VDC	2.4 VDC
Operate Time	15 ms	15 ms	15 ms	15 ms	15 ms
Release Time	8 ms	8 ms	8 ms	8 ms	8 ms
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C
Contact Material	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO)
Relay Type	General Purpose	General Purpose	General Purpose	General Purpose	General Purpose
Grade	-	-	-	-	-
Qualification	-	-	-	-	-
