Analog Devices Inc. LT3750EMS#TRPBF
- Part No.:
- LT3750EMS#TRPBF
- Manufacturer:
- Analog Devices Inc.
- Category:
- Specialized ICs
- Package:
- 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Description:
- IC FLYBACK FORW CONVERTER 10MSOP
- Quantity:
Unit Price:$8.37
Ext Price:$8.37
- Payment:
- Shipping:
Product Details
LT3750EMS#TRPBF - Capacitor Charger Controller
LT3750EMS#TRPBF from Analog Devices is a boundary-mode flyback capacitor-charger controller in a 10-lead MSOP package supplied on tape and reel.
Specifications were checked against the manufacturer data sheet and current distributor listing.
Overview
LT3750 controls an external NMOS and transformer to charge a capacitor to a resistor-programmed high voltage. Primary-side sensing avoids a high-voltage output divider.
Key Advantages
Boundary-mode switching reduces transition losses when charging a high-voltage capacitor.
Primary-side voltage sensing and the DONE indication simplify charge control.
Available in an established surface-mount or through-hole ordering format.
Electrical and environmental limits are defined by the official data sheet.
Feature Summary
Flyback capacitor-charger controller
CHARGE enable, DONE open-collector status and external NMOS gate drive
3 V to 24 V input; -40 C to 85 C operating range
10-MSOP
Package & Footprint
This ordering code uses the 10-MSOP package.
Pin Functions
Confirm exact numbering and the latest land pattern before PCB release.
Key Specifications
| Function | Boundary-mode capacitor charger |
|---|---|
| Input supply | 3 V to 24 V |
| Operating temperature | -40 C to 85 C; E-grade limits assured by characterization outside 0 C to 70 C |
| Control topology | Flyback with external NMOS and transformer |
| Current sense threshold | 78 mV nominal |
| Output target | Set by transformer ratio and external resistors |
| Charge control | CHARGE input enables or disables charging |
| Status | DONE open-collector indication |
| Primary-side sensing | No high-voltage output divider required |
| External switch | High-current NMOS gate drive |
| Package | 10-lead MSOP |
| Ordering medium | Tape and reel |
Replacement Considerations
LT3750EMS#PBF is a related product in the library. Confirm electrical behavior, package, pinout, ordering media and configuration before substitution.
Similarity of family name or package does not establish drop-in compatibility.
Manufacturer Information
Analog Devices lists both #TRPBF tape-and-reel and #PBF non-reel ordering options for the LT3750EMS. Compare the full order code and assembly media before substitution.
Applications
Charges high-voltage storage capacitors under controlled peak current.
Supports capacitor-charging power stages in pulsed lighting equipment.
Quality & Authenticity
Match the complete ordering code, package marking and reel or lot label to authorized-channel records. Inspect moisture handling and solderability requirements before assembly.
FAQ
What is the main function?
Flyback capacitor-charger controller
What package is used?
10-MSOP
Can the related part be substituted directly?
No. Validate all electrical, mechanical and configuration differences first.
Is the package image ready?
No. The registered package JPG is currently missing.
Engineering Notice
Use the latest manufacturer documentation for schematic, PCB, thermal and production approval. Distributor attributes are useful for sourcing but do not replace the official data sheet.
