Panasonic Electric Works LKG1AF-9V-16-1

Name: LKG1AF-9V-16-1
Brand: Panasonic Electric Works
SKU: LKG1AF-9V-16-1
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: LKG1AF-9V-16-1

Manufacturer:: Panasonic Electric Works

Category:: Power Relays, Over 2 Amps

Package:

Datasheet:: LKG1AF-9V-16-1.pdf

Description:: RELAY GENERAL PURPOSE

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

LKG1AF-9V-16-1 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: Panasonic Electric Works

Series:: LK-G

Packaging:: Bulk

Product Status:: Obsolete

Mounting Type:: Through Hole

Coil Voltage:: 9VDC

Contact Form:: SPST-NO (1 Form A)

Contact Rating (Current):: 16 A

Switching Voltage:: 277VAC - Max

Load - Max Switching:: 4432VA

Coil Current:: 58.8 mA

Coil Type:: Non Latching

Features:: -

Termination Style:: PC Pin

Seal Rating:: Sealed - Flux Protection

Coil Insulation:: -

Must Operate Voltage:: 6.75 VDC

Must Release Voltage:: 0.9 VDC

Operate Time:: 15 ms

Release Time:: 20 ms

Operating Temperature:: -40°C ~ 70°C

Contact Material:: Silver Tin Oxide (AgSnO)

Relay Type:: General Purpose

Grade:: -

Qualification:: -

Part Number	LKG1AF-24V-16	LKG1AF-12V-16	LKG1AF-12V-16-1	LKG1AF-24V-16-1	LKG1AF-24V-10-1
Manufacturer	Panasonic Electric Works	Panasonic Electric Works	Panasonic Electric Works	Panasonic Electric Works	Panasonic Electric Works
Series	LK-G	LK-G	LK-G	LK-G	LK-G
Packaging	Box	Tray	Bulk	Bulk	Box
Product Status	Obsolete	Obsolete	Obsolete	Obsolete	Obsolete
Mounting Type	Through Hole	Through Hole	Through Hole	Through Hole	Through Hole
Coil Voltage	24VDC	12VDC	12VDC	24VDC	24VDC
Contact Form	SPST-NO (1 Form A)	SPST-NO (1 Form A)	SPST-NO (1 Form A)	SPST-NO (1 Form A)	SPST-NO (1 Form A)
Contact Rating (Current)	16 A	16 A	16 A	16 A	10 A
Switching Voltage	277VAC - Max	277VAC - Max	277VAC - Max	277VAC - Max	277VAC - Max
Load - Max Switching	4432VA	4432VA	4432VA	4432VA	2770VA
Coil Current	22.1 mA	44.2 mA	44.2 mA	22.1 mA	22.1 mA
Coil Type	Non Latching	Non Latching	Non Latching	Non Latching	Non Latching
Features	-	-	-	-	-
Termination Style	PC Pin	PC Pin	PC Pin	PC Pin	PC Pin
Seal Rating	Sealed - Flux Protection	Sealed - Flux Protection	Sealed - Flux Protection	Sealed - Flux Protection	Sealed - Flux Protection
Coil Insulation	-	-	-	-	-
Must Operate Voltage	18 VDC	9 VDC	9 VDC	18 VDC	18 VDC
Must Release Voltage	2.4 VDC	1.2 VDC	1.2 VDC	2.4 VDC	2.4 VDC
Operate Time	15 ms	15 ms	15 ms	15 ms	15 ms
Release Time	20 ms	20 ms	20 ms	20 ms	20 ms
Operating Temperature	-40°C ~ 70°C	-40°C ~ 70°C	-40°C ~ 70°C	-40°C ~ 70°C	-40°C ~ 70°C
Contact Material	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO)	Silver Tin Oxide (AgSnO)
Relay Type	General Purpose	General Purpose	General Purpose	General Purpose	General Purpose
Grade	-	-	-	-	-
Qualification	-	-	-	-	-
