Microchip Technology JANTX2N2907AUA/TR
- Part No.:
- JANTX2N2907AUA/TR
- Manufacturer:
- Microchip Technology
- Category:
- Single Bipolar Transistors
- Package:
- 4-SMD, No Lead
- Description:
- TRANS PNP 60V 0.6A UA
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
JANTX2N2907AUA/TR Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Microchip Technology
- Series:
- -
- Package/Case:
- 4-SMD, No Lead
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Transistor Type:
- PNP
- Current - Collector (Ic) (Max):
- 600 mA
- Voltage - Collector Emitter Breakdown (Max):
- 60 V
- Vce Saturation (Max) @ Ib, Ic:
- 1.6V @ 50mA, 500mA
- Current - Collector Cutoff (Max):
- 50nA
- DC Current Gain (hFE) (Min) @ Ic, Vce:
- 100 @ 150mA, 10V
- Power - Max:
- 1.8 W
- Frequency - Transition:
- -
- Operating Temperature:
- -65°C ~ 200°C (TJ)
- Grade:
- Military
- Qualification:
- MIL-PRF-19500/291
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- UA
| Image |  |
 |
| Part Number | JANTX2N2907AUA/TR | JANTX2N2907AUA |
| Manufacturer | Microchip Technology | Microchip Technology |
| Series | - | - |
| Package/Case | 4-SMD, No Lead | 4-SMD, No Lead |
| Packaging | Tape & Reel (TR) | Bulk |
| Product Status | Active | Active |
| Transistor Type | PNP | PNP |
| Current - Collector (Ic) (Max) | 600 mA | 600 mA |
| Voltage - Collector Emitter Breakdown (Max) | 60 V | 60 V |
| Vce Saturation (Max) @ Ib, Ic | 1.6V @ 50mA, 500mA | 1.6V @ 50mA, 500mA |
| Current - Collector Cutoff (Max) | 50nA | 50nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 150mA, 10V | 100 @ 150mA, 10V |
| Power - Max | 1.8 W | 500 mW |
| Frequency - Transition | - | - |
| Operating Temperature | -65°C ~ 200°C (TJ) | -65°C ~ 200°C (TJ) |
| Grade | Military | Military |
| Qualification | MIL-PRF-19500/291 | MIL-PRF-19500/291 |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | UA | UA |
