SCHURTER Inc. ITRA-0239-D502
- Part No.:
- ITRA-0239-D502
- Manufacturer:
- SCHURTER Inc.
- Category:
- Pulse Transformers
- Package:
- Datasheet:
-
ITRA-0239-D502.pdf
- Description:
- ITRA PULSE TRANSFORMER THT 0.5A
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
ITRA-0239-D502 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- SCHURTER Inc.
- Series:
- ITRA
- Packaging:
- Bulk
- Product Status:
- Active
- Transformer Type:
- Isolation and Data Interface (Encapsulated)
- Inductance:
- 2.2mH
- ET (Volt-Time):
- -
- Turns Ratio - Primary:Secondary:
- 1:1
- Mounting Type:
- Through Hole
- Size / Dimension:
- 0.878" L x 0.894" W (22.30mm x 22.70mm)
- Height - Seated (Max):
- 0.535" (13.60mm)
- Operating Temperature:
- -25°C ~ 100°C
- Grade:
- -
- Qualification:
- -
| Image |  |
 |
|
| Part Number | ITRA-0239-D502 | ITRA-0249-D104 | ITRA-0235-D103 |
| Manufacturer | SCHURTER Inc. | SCHURTER Inc. | SCHURTER Inc. |
| Series | ITRA | ITRA | ITRA |
| Packaging | Bulk | Bulk | Bulk |
| Product Status | Active | Active | Active |
| Transformer Type | Isolation and Data Interface (Encapsulated) | Isolation and Data Interface (Encapsulated) | Isolation and Data Interface (Encapsulated) |
| Inductance | 2.2mH | 3.5mH | 2.8mH |
| ET (Volt-Time) | - | - | - |
| Turns Ratio - Primary:Secondary | 1:1 | 1:1 | 1:1 |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Size / Dimension | 0.878" L x 0.894" W (22.30mm x 22.70mm) | 0.701" L x 0.717" W (17.80mm x 18.20mm) | 0.512" L x 0.598" W (13.00mm x 15.20mm) |
| Height - Seated (Max) | 0.535" (13.60mm) | 0.512" (13.00mm) | 0.417" (10.60mm) |
| Operating Temperature | -25°C ~ 100°C | -25°C ~ 100°C | -25°C ~ 100°C |
| Grade | - | - | - |
| Qualification | - | - | - |
