Sensata-Crydom H12WD4850G-7332
- Part No.:
- H12WD4850G-7332
- Manufacturer:
- Sensata-Crydom
- Category:
- Solid State Relays (SSR)
- Package:
- Hockey Puck
- Datasheet:
-
H12WD4850G-7332.pdf
- Description:
- RELAY SSR 48-660VAC 50A
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
H12WD4850G-7332 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Sensata-Crydom
- Series:
- H12WD
- Packaging:
- -
- Product Status:
- Active
- Mounting Type:
- Chassis Mount
- Circuit:
- SPST-NO (1 Form A)
- Output Type:
- -
- Voltage - Input:
- 4 ~ 32VDC
- Voltage - Load:
- 48 V ~ 660 V
- Load Current:
- 50 A
- On-State Resistance (Max):
- -
- Termination Style:
- Screw Terminal
- Operating Temperature:
- -40°C ~ 80°C
- Supplier Device Package:
- -
- Approval Agency:
- CE, CSA, cURus, VDE
- Grade:
- -
- Qualification:
- -
| Image |  |
 |
|
|
| Part Number | H12WD4850G | H12WD4850G-10 | H12WD4850GH | H12WD4850G-7332 |
| Manufacturer | Sensata-Crydom | Sensata-Crydom | Sensata-Crydom | Sensata-Crydom |
| Series | H12WD | H12WD | H12WD | H12WD |
| Packaging | Bulk | Bulk | Bulk | - |
| Product Status | Active | Active | Active | Active |
| Mounting Type | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount |
| Circuit | SPST-NO (1 Form A) | SPST-NO (1 Form A) | SPST-NO (1 Form A) | SPST-NO (1 Form A) |
| Output Type | AC, Zero Cross | AC | AC, Zero Cross | - |
| Voltage - Input | 4 ~ 32VDC | 4 ~ 32VDC | 4 ~ 32VDC | 4 ~ 32VDC |
| Voltage - Load | 48 V ~ 660 V | 48 V ~ 660 V | 48 V ~ 660 V | 48 V ~ 660 V |
| Load Current | 50 A | 50 A | 50 A | 50 A |
| On-State Resistance (Max) | - | - | - | - |
| Termination Style | Screw Terminal | Screw Terminal | Screw Terminal | Screw Terminal |
| Operating Temperature | -40°C ~ 80°C | -40°C ~ 80°C | -40°C ~ 80°C | -40°C ~ 80°C |
| Supplier Device Package | - | - | - | - |
| Approval Agency | CE, CSA, cURus, VDE | CE, CSA, cURus, VDE | CE, CSA, cURus, VDE | CE, CSA, cURus, VDE |
| Grade | - | - | - | - |
| Qualification | - | - | - | - |
