Texas Instruments DLPA2005ERSLT
- Part No.:
- DLPA2005ERSLT
- Manufacturer:
- Texas Instruments
- Category:
- Specialized ICs
- Package:
- 48-VFQFN Exposed Pad
- Description:
- IC DLP PMIC/LED DRV 48VQFN
- Quantity:
Unit Price:$9.60
Ext Price:$9.60
- Payment:
- Shipping:
Product Details
DLPA2005ERSLT - DLP PMIC and RGB LED Driver
DLPA2005ERSLT from Texas Instruments is a DLP projector power-management and RGB LED driver IC in a 48-pin VQFN RSL package, supplied on a 250-piece small tape-and-reel carrier.
Specifications were checked against the manufacturer data sheet and current distributor listing.
Overview
DLPA2005 combines DMD supply generation and sequencing, LED current drive, a VLED buck-boost stage, a 1.1-V core buck, and a load switch for TI DLP2010, DLP2010NIR and DLP3010 systems with supported controllers.
Key Advantages
Integrates DMD supply rails, core power, sequencing and RGB LED drive in one IC.
Supports monitored, SPI-controlled projector power and LED operation in a 6 mm by 6 mm VQFN.
Available in an established surface-mount or through-hole ordering format.
Electrical and environmental limits are defined by the official data sheet.
Feature Summary
DLP power-management IC and RGB LED driver
SPI control, LED strobe inputs and DMD power rails
2.7 V to 6 V full-performance power input; -10 C to 85 C ambient
48-VFQFN Exposed Pad
Package & Footprint
This ordering code uses the 48-VFQFN Exposed Pad package.
Pin Functions
Confirm exact numbering and the latest land pattern before PCB release.
Key Specifications
| Function | DLP PMIC and RGB LED driver |
|---|---|
| DMD family | DLP2010, DLP2010NIR and DLP3010 in supported chipsets |
| Power input, full performance | 2.7 V to 6 V at VINL, VINR, VINA and VINC |
| Power input, extended range | 2.3 V to 6 V with limited parametric performance |
| SPI supply | 1.65 V to 3.6 V at VSPI |
| Ambient operating temperature | -10 C to 85 C |
| LED output current | Up to 2.4 A, application-dependent |
| DMD rails | VOFS 10 V, VBIAS 18 V, VRST -14 V as listed functional outputs |
| Core supply | 1.1-V buck, up to 600 mA |
| Load-switch input | 1.8 V to 3.6 V |
| Load-switch current | Up to 200 mA |
| SPI clock | 33 MHz maximum |
| Package | 48-pin VQFN RSL, 6 mm by 6 mm |
| Ordering medium | Small tape-and-reel, 250-piece standard package |
Replacement Considerations
DLPA2005ERSLR is a related product in the library. Confirm electrical behavior, package, pinout, ordering media and configuration before substitution.
Similarity of family name or package does not establish drop-in compatibility.
Manufacturer Information
Texas Instruments lists DLPA2005ERSLT active in the RSL 48-pin VQFN package. DLPA2005ERSLR is the same IC and package with a different carrier quantity; review assembly and ordering before switching.
Applications
Provides coordinated DMD supplies and RGB LED drive for supported DLP Pico chipsets.
Supports compact DLP illumination and power sequencing in sensing equipment.
Quality & Authenticity
Match the complete ordering code, package marking and reel or lot label to authorized-channel records. Inspect moisture handling and solderability requirements before assembly.
FAQ
What is the main function?
DLP power-management IC and RGB LED driver
What package is used?
48-VFQFN Exposed Pad
Can the related part be substituted directly?
No. Validate all electrical, mechanical and configuration differences first.
Is the package image ready?
No. The registered package JPG is currently missing.
Engineering Notice
Use the latest manufacturer documentation for schematic, PCB, thermal and production approval. Distributor attributes are useful for sourcing but do not replace the official data sheet.
DLPA2005ERSLT Information
- Specifications
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Texas Instruments
- Series:
- -
- Package/Case:
- 48-VFQFN Exposed Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Programmable:
- Not Verified
- Type:
- DLP PMIC, LED Driver
- Applications:
- DLP® Pico™ Projectors, Mobile Sensing
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 48-VQFN (6x6)
- Grade:
- -
- Qualification:
- -
- Include Parts
