Sensata Technologies, Inc. DBT71210
- Part No.:
- DBT71210
- Manufacturer:
- Sensata Technologies, Inc.
- Category:
- Reed Relays
- Package:
- Description:
- RELAY REED SPST-NC 2A 12V
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
DBT71210 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Sensata Technologies, Inc.
- Series:
- DB
- Packaging:
- Tray
- Product Status:
- Active
- Mounting Type:
- Through Hole
- Coil Voltage:
- 12VDC
- Contact Form:
- SPST-NC (1 Form B)
- Contact Rating (Current):
- 2 A
- Switching Voltage:
- 7000VAC, 7000VDC - Max
- Coil Current:
- 50 mA
- Coil Type:
- Non Latching
- Features:
- -
- Termination Style:
- PC Pin
- Seal Rating:
- -
- Must Operate Voltage:
- 9 VDC
- Must Release Voltage:
- 1.25 VDC
- Operate Time:
- 2 ms
- Release Time:
- 3 ms
- Operating Temperature:
- -20°C ~ 70°C
- Contact Material:
- Tungsten (W)
| Image |  |
 |
|
 |
 |
| Part Number | DBT71210 | DBT71210S | DBT71210U | DBT71210P | DBT71210FU |
| Manufacturer | Sensata Technologies, Inc. | Sensata Technologies, Inc. | Sensata Technologies, Inc. | Sensata Technologies, Inc. | Sensata Technologies, Inc. |
| Series | DB | DB | DB | DB | DB |
| Packaging | Tray | Bulk | Bulk | Bulk | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| Mounting Type | Through Hole | Chassis Mount | Through Hole | Chassis Mount | Through Hole |
| Coil Voltage | 12VDC | 12VDC | 12VDC | 12VDC | 12VDC |
| Contact Form | SPST-NC (1 Form B) | SPST-NC (1 Form B) | SPST-NC (1 Form B) | SPST-NC (1 Form B) | SPST-NC (1 Form B) |
| Contact Rating (Current) | 2 A | 2 A | 2 A | 2 A | 2 A |
| Switching Voltage | 7000VAC, 7000VDC - Max | 7000VAC, 7000VDC - Max | 7000VAC, 7000VDC - Max | 7000VAC, 7000VDC - Max | 7000VAC, 7000VDC - Max |
| Coil Current | 50 mA | 50 mA | 50 mA | 50 mA | 50 mA |
| Coil Type | Non Latching | Non Latching | Non Latching | Non Latching | Non Latching |
| Features | - | - | - | - | - |
| Termination Style | PC Pin | Quick Connect - 0.250" (6.3mm) | PC Pin | Solder Turret | PC Pin, Wire Leads |
| Seal Rating | - | - | - | - | - |
| Must Operate Voltage | 9 VDC | 9 VDC | 9 VDC | 9 VDC | 9 VDC |
| Must Release Voltage | 1.25 VDC | 1.25 VDC | 1.25 VDC | 1.25 VDC | 1.25 VDC |
| Operate Time | 2 ms | 2 ms | 2 ms | 2 ms | 2 ms |
| Release Time | 3 ms | 3 ms | 3 ms | 3 ms | 3 ms |
| Operating Temperature | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C |
| Contact Material | Tungsten (W) | Tungsten (W) | Tungsten (W) | Tungsten (W) | Tungsten (W) |
