Texas Instruments CD4536BE
- Part No.:
- CD4536BE
- Manufacturer:
- Texas Instruments
- Category:
- Programmable Timers and Oscillators
- Package:
- 16-DIP (0.300", 7.62mm)
- Datasheet:
-
CD4536BE.pdf
- Description:
- IC OSC PROG TIMER 5MHZ 16DIP
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
CD4536BE Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Texas Instruments
- Series:
- -
- Package/Case:
- 16-DIP (0.300", 7.62mm)
- Packaging:
- Bulk
- Product Status:
- Active
- Type:
- Programmable Timer
- Count:
- 2 ~ 2²⁴
- Frequency:
- 5MHz
- Voltage - Supply:
- 3V ~ 18V
- Current - Supply:
- 3 mA
- Operating Temperature:
- -55°C ~ 125°C
- Supplier Device Package:
- 16-PDIP
- Mounting Type:
- Through Hole
- Grade:
- -
- Qualification:
- -
| Image |  |
|
 |
| Part Number | CD4536BE | CD4536BEG4 | CD4536BEE4 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments |
| Series | - | - | - |
| Package/Case | 16-DIP (0.300", 7.62mm) | 16-DIP (0.300", 7.62mm) | 16-DIP (0.300", 7.62mm) |
| Packaging | Bulk | Tube | Tube |
| Product Status | Active | Discontinued at Digi-Key | Active |
| Type | Programmable Timer | Programmable Timer | Programmable Timer |
| Count | 2 ~ 2²⁴ | 2 ~ 2²⁴ | 2 ~ 2²4 |
| Frequency | 5MHz | 5MHz | 5MHz |
| Voltage - Supply | 3V ~ 18V | 3V ~ 18V | 3V ~ 18V |
| Current - Supply | 3 mA | 3 mA | 100 µA |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C (TA) |
| Supplier Device Package | 16-PDIP | 16-PDIP | 16-PDIP |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Grade | - | - | - |
| Qualification | - | - | - |
