Diodes Incorporated AP62300WU-7
- Part No.:
- AP62300WU-7
- Manufacturer:
- Diodes Incorporated
- Package:
- SOT-23-6 Thin, TSOT-23-6
- Description:
- IC REG BUCK ADJ 3A TSOT26
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
Product Details
AP62300WU-7 - 3A Synchronous Buck Converter 4.5V–18V Input (SOT23-6)
AP62300WU-7 is a high-efficiency synchronous step-down (buck) DC-DC converter from Diodes Incorporated, designed to deliver up to 3A output current with wide input voltage support and excellent power efficiency for compact power designs.
This page is written for product identification and engineering selection guidance. Always verify final limits using the manufacturer's latest datasheet revision for design sign-off.
Overview
AP62300WU-7 is a fully integrated synchronous buck converter optimized for high efficiency and compact PCB layout. It integrates both high-side and low-side MOSFETs, reducing external component count and simplifying power design.
With a wide input voltage range and high switching frequency, it is ideal for distributed power systems, point-of-load (POL) regulation, and embedded applications requiring stable and efficient DC voltage conversion.
Key Advantages
Synchronous design minimizes power loss and improves system efficiency.
Supports up to 3A load, suitable for processors and high-current loads.
Integrated MOSFETs reduce external components and PCB footprint.
Includes overcurrent, thermal shutdown, and undervoltage protections.
Feature Summary
Operates from 4.5V to 18V, suitable for various power rails.
Up to 3A continuous load capability.
Allows use of small inductors and capacitors for compact designs.
Includes OCP, OTP, and UVLO for reliable system operation.
Package & Footprint
The AP62300WU-7 is housed in a compact SOT23-6 package, ideal for space-constrained applications and high-density PCB layouts.
(replace with real package photo/drawing)
- Use wide copper traces for high current paths.
- Place input/output capacitors close to IC pins.
- Ensure proper grounding to minimize switching noise.
Refer to the datasheet for recommended layout guidelines.
Pin Functions
The AP62300WU-7 includes essential control and power pins for buck operation.
(replace with official pinout drawing)
Key Specifications
| Device Type | Synchronous Buck Converter |
|---|---|
| Input Voltage | 4.5V – 18V |
| Output Current | Up to 3A |
| Switching Frequency | High-frequency operation (typ. ~1MHz class) |
| Efficiency | Up to ~90% (typ., application dependent) |
| Package | SOT23-6 |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C to +85°C / +125°C (variant dependent) |
Equivalent
Common alternatives to AP62300WU-7 include:
Engineering note: Verify switching frequency, compensation, and transient response when replacing power ICs.
Manufacturer Information
Diodes Incorporated is a global manufacturer of high-quality semiconductor products, including power management ICs, analog devices, and discrete components.
- Core strengths: Power ICs, discretes, analog and mixed-signal
- Markets: Automotive, industrial, consumer electronics
- Resources: Datasheets, reference designs, application notes
Applications
The AP62300WU-7 is widely used in efficient power conversion systems:
Point-of-Load Regulation
Efficient voltage step-down for processors and digital ICs.
Embedded Systems
Provides stable power for MCUs and logic circuits.
Industrial Equipment
Used in distributed power architectures.
Consumer Electronics
Power conversion for compact and portable devices.
Quality & Authenticity
- Incoming inspection: package and marking verification
- Traceability: supplier and lot tracking
- Anti-counterfeit: recommended for power IC sourcing
FAQ
Is AP62300WU-7 suitable for 12V input systems?
Does it require external MOSFETs?
What should be considered for layout?
Disclaimer
AP62300WU-7 Information
- Specifications
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Diodes Incorporated
- Series:
- -
- Package/Case:
- SOT-23-6 Thin, TSOT-23-6
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Function:
- Step-Down
- Output Configuration:
- Positive
- Topology:
- Buck
- Output Type:
- Adjustable
- Number of Outputs:
- 1
- Voltage - Input (Min):
- 4.2V
- Voltage - Input (Max):
- 18V
- Voltage - Output (Min/Fixed):
- 0.8V
- Voltage - Output (Max):
- 7V
- Current - Output:
- 3A
- Frequency - Switching:
- 750kHz
- Synchronous Rectifier:
- Yes
- Operating Temperature:
- -40°C ~ 85°C (TA)
- Grade:
- Automotive
- Qualification:
- AEC-Q100
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- TSOT-26
- Include Parts
