Abracon LLC AIAP-02-5R6K
- Part No.:
- AIAP-02-5R6K
- Manufacturer:
- Abracon LLC
- Category:
- Fixed Inductors
- Package:
- Axial
- Datasheet:
-
AIAP-02-5R6K.pdf
- Description:
- FIXED IND 5.6UH 5.6A 24 MOHM TH
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
AIAP-02-5R6K Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Abracon LLC
- Series:
- AIAP-02
- Package/Case:
- Axial
- Packaging:
- Bulk
- Product Status:
- Active
- Type:
- -
- Material - Core:
- Ferrite
- Inductance:
- 5.6 µH
- Tolerance:
- ±10%
- Current Rating (Amps):
- 5.6 A
- Current - Saturation (Isat):
- -
- Shielding:
- Unshielded
- DC Resistance (DCR):
- 24mOhm Max
- Q @ Freq:
- -
- Frequency - Self Resonant:
- -
- Ratings:
- -
- Operating Temperature:
- -40°C ~ 85°C
- Inductance Frequency - Test:
- 1 kHz
- Features:
- -
- Mounting Type:
- Through Hole
- Supplier Device Package:
- Axial
- Size / Dimension:
- 0.252" Dia x 0.551" L (6.40mm x 14.00mm)
- Height - Seated (Max):
- -
| Image |  |
|
|
|
 |
| Part Number | AIAP-01-4R7K-T | AIAP-01-470K-T | AIAP-01-120K-T | AIAP-01-222K-T | AIAP-02-472K |
| Manufacturer | Abracon LLC | Abracon LLC | Abracon LLC | Abracon LLC | Abracon LLC |
| Series | AIAP-01 | AIAP-01 | AIAP-01 | AIAP-01 | AIAP-02 |
| Package/Case | Axial | Axial | Axial | Axial | Axial |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| Type | Wirewound | Wirewound | Wirewound | Wirewound | Wirewound |
| Material - Core | - | - | - | - | - |
| Inductance | 4.7 µH | 47 µH | 12 µH | 2.2 mH | 4.7 mH |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% |
| Current Rating (Amps) | 1.7 A | 760 mA | 1.4 A | 100 mA | 180 mA |
| Current - Saturation (Isat) | - | - | - | - | - |
| Shielding | Unshielded | Unshielded | Unshielded | Unshielded | Unshielded |
| DC Resistance (DCR) | 68mOhm Max | 350mOhm Max | 110mOhm Max | 19Ohm Max | 9.66Ohm Max |
| Q @ Freq | - | - | - | - | - |
| Frequency - Self Resonant | 86MHz | 6MHz | 17MHz | 640kHz | - |
| Ratings | - | - | - | - | - |
| Operating Temperature | -40°C ~ 105°C | -40°C ~ 105°C | -40°C ~ 105°C | -40°C ~ 105°C | -40°C ~ 85°C |
| Inductance Frequency - Test | 7.9 MHz | 1 kHz | 1 kHz | 1 kHz | 1 kHz |
| Features | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Supplier Device Package | - | - | - | - | - |
| Size / Dimension | 0.130" Dia x 0.360" L (3.30mm x 9.14mm) | 0.130" Dia x 0.360" L (3.30mm x 9.14mm) | 0.130" Dia x 0.360" L (3.30mm x 9.14mm) | 0.130" Dia x 0.360" L (3.30mm x 9.14mm) | 0.252" Dia x 0.551" L (6.40mm x 14.00mm) |
| Height - Seated (Max) | - | - | - | - | - |
