TE Connectivity Aerospace, Defense and Marine 6-1617672-4
- Part No.:
- 6-1617672-4
- Manufacturer:
- TE Connectivity Aerospace, Defense and Marine
- Category:
- Signal Relays, Up to 2 Amps
- Package:
- Description:
- RELAY GEN PURPOSE DPDT 1A 26.5V
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
6-1617672-4 Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- TE Connectivity Aerospace, Defense and Marine
- Series:
- MSD, CII
- Packaging:
- Bulk
- Product Status:
- Active
- Mounting Type:
- Through Hole
- Coil Voltage:
- 26.5VDC
- Contact Form:
- DPDT (2 Form C)
- Contact Rating (Current):
- 1 A
- Switching Voltage:
- 115VAC, 28VDC - Max
- Load - Max Switching:
- 115VA, 28W
- Coil Current:
- 8 mA
- Coil Type:
- Non Latching
- Features:
- Diode
- Termination Style:
- PC Pin
- Seal Rating:
- Sealed - Hermetically
- Coil Insulation:
- -
- Must Operate Voltage:
- 14 VDC
- Must Release Voltage:
- 1.4 VDC
- Operate Time:
- 4 ms
- Release Time:
- 7.5 ms
- Operating Temperature:
- -65°C ~ 125°C
- Contact Material:
- Silver Palladium (AgPd), Gold (Au)
- Relay Type:
- General Purpose
- Grade:
- -
- Qualification:
- -
| Image |  |
 |
|
|
|
| Part Number | 6-1617039-9 | 6-1617039-1 | 6-1617542-0 | 6-1617543-5 | 6-1617347-5 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| Series | HMS, CII | HMS, CII | MGA, CII | MST, CII | 3SBC, CII |
| Packaging | Bulk | Bulk | Bulk | Bulk | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| Mounting Type | Chassis Mount | Through Hole | Through Hole | Through Hole | - |
| Coil Voltage | 27 ~ 56VDC | - | 12VDC | 6VDC | - |
| Contact Form | DPDT (2 Form C) | DPDT (2 Form C) | DPDT (2 Form C) | DPDT (2 Form C) | DPDT (2 Form C) |
| Contact Rating (Current) | 2 A | 2 A | 1 A | 1 A | 2 A |
| Switching Voltage | 115VAC, 28VDC - Max | - | 115VAC, 28VDC - Max | 115VAC, 28VDC - Max | 115VAC, 28VDC - Max |
| Load - Max Switching | 300VA, 56W | - | 115VA, 28W | 115VA, 28W | 230VA, 56W |
| Coil Current | - | - | 30.8 mA | 30 mA | - |
| Coil Type | Non Latching | Non Latching | Non Latching | Non Latching | Non Latching |
| Features | - | - | - | Diode | - |
| Termination Style | PC Pin | PC Pin | PC Pin | PC Pin | - |
| Seal Rating | Sealed - Hermetically | - | Sealed - Hermetically | Sealed - Hermetically | Sealed - Hermetically |
| Coil Insulation | - | - | - | - | - |
| Must Operate Voltage | 18 VDC | - | 7 VDC | 3.4 VDC | - |
| Must Release Voltage | 1.8 VDC | - | 0.63 VDC | 0.28 VDC | - |
| Operate Time | 6 ms | 6 ms | 2 ms | 4 ms | - |
| Release Time | 5 ms | 5 ms | 1.5 ms | 7.5 ms | - |
| Operating Temperature | -65°C ~ 125°C | -65°C ~ 125°C | -65°C ~ 125°C | -65°C ~ 125°C | -65°C ~ 125°C |
| Contact Material | Silver (Ag), Gold (Au) | - | Silver Palladium (AgPd), Gold (Au) | Silver Palladium (AgPd), Gold (Au) | - |
| Relay Type | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
