Littelfuse Inc. 600R150-C
- Part No.:
- 600R150-C
- Manufacturer:
- Littelfuse Inc.
- Category:
- PTC Resettable Fuses
- Package:
- -
- Description:
- POLYFUSE RADIAL
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
600R150-C Information
- Specifications
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Littelfuse Inc.
- Package/Case:
- -
- Series:
- -
- Packaging:
- Bulk
- Product Status:
- Obsolete
- Type:
- -
- Voltage - Max:
- -
- Current - Hold (Ih) (Max):
- -
- Current - Trip (It):
- -
- Current - Max:
- -
- Time to Trip:
- -
- Resistance - Initial (Ri) (Min):
- -
- Resistance - Post Trip (R1) (Max):
- -
- Resistance - 25°C (Typ):
- -
- Operating Temperature:
- -
- Grade:
- -
- Qualification:
- -
- Ratings:
- -
- Mounting Type:
- -
- Size / Dimension:
- -
- Height - Seated (Max):
- -
- Thickness (Max):
- -
- Lead Spacing:
- -
| Image |  |
 |
 |
 |
 |
| Part Number | 600R150F | 600R150ZR | 600R150-RBZR | 600R150-RAF | 600R150-RAZR |
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Package/Case | Radial, Disc | Radial, Disc | Radial, Disc | Radial, Disc | Radial, Disc |
| Series | POLY-FUSE®, 600R | POLY-FUSE®, 600R | POLY-FUSE®, 600R | POLY-FUSE®, 600R | POLY-FUSE®, 600R |
| Packaging | Bulk | Cut Tape (CT) | Cut Tape (CT) | Bulk | Cut Tape (CT) |
| Product Status | Active | Active | Active | Active | Obsolete |
| Type | Polymeric | Polymeric | Polymeric | Polymeric | Polymeric |
| Voltage - Max | 60V (600V Int) | 60V (600V Int) | 60V (600V Int) | 60V (600V Int) | 60V (600V Int) |
| Current - Hold (Ih) (Max) | 150 mA | 150 mA | 150 mA | 150 mA | 150 mA |
| Current - Trip (It) | 300 mA | 300 mA | 300 mA | 300 mA | 300 mA |
| Current - Max | 3 A | 3 A | 3 A | 3 A | 3 A |
| Time to Trip | 4 s | 4 s | 3 s | 4 s | 4 s |
| Resistance - Initial (Ri) (Min) | 6 Ohms | 6 Ohms | 9 Ohms | 7 Ohms | 7 Ohms |
| Resistance - Post Trip (R1) (Max) | 17 Ohms | 17 Ohms | 22 Ohms | 20 Ohms | 20 Ohms |
| Resistance - 25°C (Typ) | - | - | - | - | - |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Ratings | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Size / Dimension | 0.354" L x 0.181" W (9.00mm x 4.60mm) | 0.354" L x 0.181" W (9.00mm x 4.60mm) | 0.354" L x 0.181" W (9.00mm x 4.60mm) | 0.354" L x 0.181" W (9.00mm x 4.60mm) | 0.354" L x 0.181" W (9.00mm x 4.60mm) |
| Height - Seated (Max) | 0.492" (12.50mm) | 0.492" (12.50mm) | 0.492" (12.50mm) | 0.492" (12.50mm) | 0.492" (12.50mm) |
| Thickness (Max) | - | - | - | - | - |
| Lead Spacing | 0.201" (5.10mm) | 0.201" (5.10mm) | 0.201" (5.10mm) | 0.201" (5.10mm) | 0.201" (5.10mm) |
