Microchip Technology 2N6301

Product attributes

Attribute value

Manufacturer:

Microchip Technology

Series:

-

Package/Case:

TO-213AA, TO-66-2

Packaging:

Bulk

Product Status:

Active

Transistor Type:

NPN - Darlington

Current - Collector (Ic) (Max):

8 A

Voltage - Collector Emitter Breakdown (Max):

80 V

Vce Saturation (Max) @ Ib, Ic:

3V @ 80mA, 8A

Current - Collector Cutoff (Max):

500µA

DC Current Gain (hFE) (Min) @ Ic, Vce:

750 @ 4A, 3V

Power - Max:

75 W

Frequency - Transition:

-

Operating Temperature:

-55°C ~ 200°C (TJ)

Grade:

-

Qualification:

-

Mounting Type:

Through Hole

Supplier Device Package:

TO-66 (TO-213AA)
