TE Connectivity Potter & Brumfield Relays 1-1462039-8

Name: 1-1462039-8
Brand: TE Connectivity Potter & Brumfield Relays
SKU: 1-1462039-8
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Compare

Part No.:: 1-1462039-8

Manufacturer:: TE Connectivity Potter & Brumfield Relays

Category:: Power Relays, Over 2 Amps

Package:

Description:: RELAY TELECOM DPDT 5A 12V

Quantity:: Add To Cart Add To RFQ list

Unit Price:$0

Ext Price:$0

Payment:

Shipping:

1-1462039-8 Information

Specifications
Comparison
Tags

Product attributes: Attribute value

Manufacturer:: TE Connectivity Potter & Brumfield Relays

Series:: IM, AXICOM

Packaging:: Tape & Reel (TR)

Product Status:: Active

Mounting Type:: Surface Mount

Coil Voltage:: 12VDC

Contact Form:: DPDT (2 Form C)

Contact Rating (Current):: 5 A

Switching Voltage:: 250VAC, 220VDC - Max

Load - Max Switching:: 62.5VA, 60W

Coil Current:: 11.6 mA

Coil Type:: Non Latching

Features:: -

Termination Style:: Gull Wing

Seal Rating:: Sealed - Hermetically

Coil Insulation:: -

Must Operate Voltage:: 9 VDC

Must Release Voltage:: 1.2 VDC

Operate Time:: 3 ms

Release Time:: 3 ms

Operating Temperature:: -40°C ~ 85°C

Contact Material:: Silver Nickel (AgNi), Gold (Au)

Relay Type:: Telecom

Grade:: -

Qualification:: -

Part Number	1-1462039-8	1-1462039-9	1956226-2	1462039-9	1415898-4
Manufacturer	TE Connectivity Potter & Brumfield Relays	TE Connectivity Potter & Brumfield Relays	TE Connectivity Potter & Brumfield Relays	TE Connectivity Potter & Brumfield Relays	TE Connectivity Potter & Brumfield Relays
Series	IM, AXICOM	IM, AXICOM	RE, SCHRACK	IM, AXICOM	RT, SCHRACK
Packaging	Tape & Reel (TR)	Tape & Reel (TR)	Tube	Tape & Reel (TR)	Bulk
Product Status	Active	Active	Active	Active	Active
Mounting Type	Surface Mount	Surface Mount	Through Hole	Surface Mount	Through Hole
Coil Voltage	12VDC	4.5VDC	24VDC	2.4VDC	3VDC
Contact Form	DPDT (2 Form C)	DPDT (2 Form C)	SPST-NO (1 Form A)	DPDT (2 Form C)	SPST-NO (1 Form A)
Contact Rating (Current)	5 A	5 A	6 A	5 A	16 A
Switching Voltage	250VAC, 220VDC - Max	250VAC, 220VDC - Max	400VAC - Max	250VAC, 220VDC - Max	400VAC - Max
Load - Max Switching	62.5VA, 60W	62.5VA, 60W	2400VA	62.5VA, 60W	6400VA
Coil Current	11.6 mA	22.2 mA	8.3 mA	41.7 mA	200 mA
Coil Type	Non Latching	Latching, Single Coil	Non Latching	Latching, Single Coil	Latching, Dual Coil
Features	-	-	-	-	-
Termination Style	Gull Wing	Gull Wing	PC Pin	Gull Wing	PC Pin
Seal Rating	Sealed - Hermetically	Sealed - Hermetically	Sealed - Fully	Sealed - Hermetically	Sealed - Flux Protection
Coil Insulation	-	-	Class F	-	Class F
Must Operate Voltage	9 VDC	3.38 VDC	16.8 VDC	1.8 VDC	2.1 VDC
Must Release Voltage	1.2 VDC	-	2.4 VDC	-	1.8 VDC
Operate Time	3 ms	3 ms	10 ms	3 ms	10 ms
Release Time	3 ms	3 ms	5 ms	3 ms	5 ms
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 70°C	-40°C ~ 85°C	-40°C ~ 105°C
Contact Material	Silver Nickel (AgNi), Gold (Au)	Silver Nickel (AgNi), Gold (Au)	Silver Nickel (AgNi), Gold (Au)	Silver Nickel (AgNi), Gold (Au)	Silver Tin Oxide (AgSnO), Tungsten (W)
Relay Type	Telecom	Telecom	General Purpose	Telecom	General Purpose
Grade	-	-	-	-	-
Qualification	-	-	-	-	-
